Aerial Cables Network Cable Drop Wire 1*2*0.5cu

Zhejiang Kuayue Cable Co., Ltd.
  • Application：Telephone Cable
  • Conductor Material：Copper
  • Cover Material：PE
  • Type：Cat 3
  • Material Shape：Flat Wire
  • Conductor Type：Solid

Base Info

  • Model NO.：drop wire
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS, UL
  • Model：Hyyc
  • Brand：Hanli
  • Transport Package：305,500,1000m
  • Specification：1X2X0.5CU
  • Trademark：Hanli
  • Origin：Zhejiang
  • HS Code：8544491100
  • Production Capacity：1000000,Ear

Description

Basic Info.

Model NO. drop wire Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS, UL Model Hyyc Brand Hanli Transport Package 305/500/1000m Specification 1X2X0.5CU Trademark Hanli Origin Zhejiang HS Code 8544491100 Production Capacity 1000000/Ear

Product Description

1.Conductor :0.48CU,0.5CU,0.51CU or CCA,
2,insulation:HDPE ID:0.920mm
3,Twisted pairs..
4,jacket :PVC,LZSH or PE
5,Nominal diameter: 2.4X4.2±0.2mm
6,Average thickness: 0.55mm
7,Frequency: 32MHz
8,Resistance Unbalance,maximum : 4.5%
9,Mutual Capacitance :5.6 nF/100 m @ 1 kHz
10,Dielectric Test: DC 2500V/2min at 20ºC
11, Application: 100Base T4, 100Base-TX,100VG-AnyLan,1000 Base-T(Gigabit Ethernet),155Mbps ATM,622Mbps ATM.
12. Standard: international ISO/IEC 11801; USA ANSI/TIA/EIA-568B.
13,Operating temperature range: -20 to 75°C
14,305meters pull box or 500meters wooden drum
15,.OEM order is welcome

Welcome to visit our factory and  get our samples.
  Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
 Aerial Cables Network Cable Drop Wire 1*2*0.5cuAerial Cables Network Cable Drop Wire 1*2*0.5cuAerial Cables Network Cable Drop Wire 1*2*0.5cuAerial Cables Network Cable Drop Wire 1*2*0.5cuAerial Cables Network Cable Drop Wire 1*2*0.5cuAerial Cables Network Cable Drop Wire 1*2*0.5cu
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
