• Model NO.：WT2019ENA
• Shape：Round
• Interface Type：AC,DC
• Certification：RoHS, ISO9001, UL, CCC
• Brand：Wiretec
• Transport Package：Canbus
• Specification：per requested or ragular
• Trademark：NOR
• Origin：China
• HS Code：8544421100
• Production Capacity：10000 Set,Day

Basic Info.

Model NO. WT2019ENA Shape Round Interface Type AC/DC Certification RoHS, ISO9001, UL, CCC Brand Wiretec Transport Package Canbus Specification per requested or ragular Trademark NOR Origin China HS Code 8544421100 Production Capacity 10000 Set/Day

Product Description

We are China Factory of Wire harness and Shielded Over Molded XLPE Profi Bus Profi Net CanBus Asi Sensor Cable.
We produce high performance Industrial Pre-Wired M12 Connector Cable 5-Pin Female A-Coding 3M/10FT PVC Line.


• Cable Length: 3 meters / 10 feet to 20 Meters, Coding: A-coding interface, Contacts: 5 pins layout, Gender: Female, Shielding Function: Unshielded, Type: 180° Circular.
• Rated voltage: 125V, Current per contact (40°C): Max 4A, Volume resistance:≤5MΩ, Temperature range ( Insulator / Wire): -20 to 85°C .
• Wire gauge:22AWG/0.34mm², Cable Material: PVC ,Cable Material :White/black STPE high-flex,overmolding cable.
• Standard: IEC 61076-2-101, Flame Retardant Rating: UL94-HB, IP Rating: IP67, Certification: CE / ISO 9001.
• Application:It is widely used in industrial automation,PLC system,and commercial electronics,such as wind power generation,high-speed rail, industrial Camera automobile manufacturing, intelligent transportation, intelligent manufacturing and so on.

Product Features
We assembly M12 series connector cable, it applies to Data Communication and I/O connection on-site installation.

Widely used in data transmission, micro-electrical transmission.

Product Specifications
Product Type: Single-ended pre-injection
Connector Type: M12 Circular interface
Interface Type: A-coding
Cable Cover Material: PVC
Number of Pins: 5-pole
Cable Diameter: ø5.3±0.1mm
Cable Core: 5x0.34 mm²
Cable Length:3 meter / 10 ft
Rated Voltage:125V
Temperature Range ( Insulator / Wire ): -25°C to 85°C / -40°C to 85°C
Protection Class: IP67
Shielding Function: Unshielded
Main Color: Black

Our factory is an enterprise devoted to the development, design, production and sale of wire harness and cables.The products are mainly applied to industry, computer peripheral, communication, automotive, marine, electrical appliances, medical and other industries; Such as MDR, USB, SATA, SCSI, DVI, HDMI, VGA, 1394, ESATA, IEEE488, network cable, AUDIO, vehicular TV cable, HARNESS cable and so on.

Products include precast connectors, field wiring connectors, distribution boxes, splitters, distributors, etc. Can easily and quickly connect various sensors, actuators, and power supplies on the industrial site.

Modern industrial production has increasingly stringent requirements for the safety, reliability, and rapid installation of the connection systems in all its aspects. We can provide customers with safe, reliable, convenient and quick overall connection scheme.
