TUV Certified Fg16or16 Power and Signal Flexible Cable 0.6/1kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Installation
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：Hepr

Base Info

  • Model NO.：FG16OR16
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemFG16OR16 Power Cables ConductorCopper (as client's required)InsulationHEPR Compound, hard ethvlene-propylene-rubber (as client's required)Outer SheathAnti-abrasive PVC compound (as client's required)Nominal Voltage600/1000VTest Voltage4000VTemperature RatingMinimum Temperature Of  Installation: 0 °CMaximum Temperature On Use: 90°CColorOptionalCertificationTUV CECharacteristicAnti-abrasive
Flame-retardant
Fire resistant
High FlexibleApplicationDistribution and signal power cable for static application indoor and outdoor, in ground, in water, within facilities, in cable canals, in conditions where the cable is not exposed either to systematic mechanical stress or heavier tensile strain. Used in industrial plants or household installations, where heavier current and thermal loads are expected (operating temperature of conductor up to 90 °C), in conditions requiring higher flexibility and better resistance to combustion. Cable is under scope of EN 50575:2014+EN 50575/A1:2016 standard and Compliant with the requirements of European Construction Product Regulation.
