• Model NO.：DJYPV DJYPVP SJYVP DJYPV22
• Material Shape：Round Wire
• Range of Application：Refractory
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Feiya
• Color：Black Red Yellow, According to Voltage Level
• Whether It Is Environmentally Friendly：Yes
• Whether Quality Inspection：Provide Inspection Certificate
• Standard：Customized According to Specified National Standar
• OEM/ODM：Accepted
• Core：Single Core and Multicore
• Transport Package：Standard Export Packaging
• Specification：International General Specifications
• Trademark：Fengda
• Origin：Tianjin, China(Mainland)
• HS Code：8544492100
• Production Capacity：100000,Day

Basic Info.

Model NO. DJYPV DJYPVP SJYVP DJYPV22 Material Shape Round Wire Range of Application Refractory Certification ISO9001, CE, UL, CCC, RoHS, VDE Brand Feiya Color Black Red Yellow, According to Voltage Level Whether It Is Environmentally Friendly Yes Whether Quality Inspection Provide Inspection Certificate Standard Customized According to Specified National Standar OEM/ODM Accepted Core Single Core and Multicore Transport Package Standard Export Packaging Specification International General Specifications Trademark Fengda Origin Tianjin, China(Mainland) HS Code 8544492100 Production Capacity 100000/Day

Product Description



1. Executive standard
It is manufactured acconding to TICW/06-2009 <The cables for computer and instrument>.

It is used as signal transmission and connection of checking appliances of distribution system, computer system and automatic system of power-generating metallurgy petroline chemistry.


2. Characteristics

1. The permissble long-term working temperature of the cable conductor: XLPE insulated is 90°C, PVC insulated is 70 °C.During the cable laying, the ambient temperature must be above 0 °C.

2. The permissible bending radius in cable laying and installing.

a). For unarmoured cable, it shall not be less than 6 times of external diameter of cable.

b). For armoured or copper tape screened cable, it shall not be less than 12 times of the external diameter of cable.

c). For the flexible cable with screen layers, it shall not be less than 6 times of the external diameter of cable.

3. Type and Designation



Code Designation	Constructions
DJYPV	Copper Conductor, PE Insulation, Copper Wire Braid Individual Shield, PVC Sheath
DJYPVP	Copper Conductor, PE Insulation, Copper Wire Braid Individual Shield and Overall Shield, PVC Sheath
DJYVP	Copper Conductor, PE Insulation, Copper Wire Braid Overall Shield, PVC Sheath
DJYPV22	Copper Conductor, PE Insulation, Cu Wire Braid Individual Shield, Double Steel Tape Armored,PVC Sheath
