UL10126 600V Heat Resistant Tinned Bare Copper Conductor Electrical Wire
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：for General Purpose Internal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL10126
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, UL, RoHS, Reach
- Brand：B&T
- Rated Temperature：80 ºC
- Rated Voltage：300V
- According to：UL Subject758, UL1581, C22.2
- Test：Passes UL VW-1 & FT1 Vertical Flame Test
- Performance：for General Purpose Internal Wiring of Appliance
- Conductor：Stranded, Tinned or Bare Copper Conductor
- Capacity：300,000km Annual
- Color：Could Be Customized Color
- Delivery Time：7-15days
- Package：Coil or Spool Packing
- Transport Package：610feet in Roll
- Specification：UL1061
- Trademark：B&T
- Origin：Xiamen, Fujian
- HS Code：8544492100
- Production Capacity：300, 000km
Description
(mm) Nom. Min. Nom. Tol. 10 37/0.42 3.54 2.94 0.40 0.33 3.75 ±0.15 12 37/0.374 5.64 2.62 0.40 0.33 3.42 ±0.15 14 19/0.361 8.96 1.85 0.25 0.23 2.35 ±0.10 16 19/0.287 14.60 1.50 0.25 0.23 2.00 ±0.10 18 19/0.235 23.20 1.18 0.25 0.23 1.70 ±0.10 20 19/0.19 36.70 0.95 0.25 0.23 1.45 ±0.10 22 19/0.15 59.40 0.76 0.25 0.23 1.26 ±0.10 24 7/0.20 94.20 0.60 0.25 0.23 1.10 ±0.10 26 7/0.16 150.00 0.48 0.25 0.23 1.00 ±0.10 28 7/0.127 239.00 0.38 0.25 0.23 0.90 ±0.10 30 1/0.254 361.00 0.254 0.25 0.23 0.75 ±0.10
