Sst Loose Tube Optical Fiber Composite Overhead Ground Wire Stranded Opgw
DONGGUAN TW-SCIE CO., LTD.- Application：Communication
- Type：Single-mode Fiber
- Material Shape：Round Wire
- Allowed Lateral Pressure：>1000(N,100mm)
- Allowed Tensile Strength：>10000N
- Core：2-288 Opgw Optic Fiber Cable
Base Info
- Certification：RoHS, CE, ISO9001, Reach, Tlc etc
- Brand：Tw-Scie, ODM, OEM
- Sheath Material：as Wire
- Model No：Opgw Optic Fiber Cable
- Fiber Core：2-288 Core
- Fiber Type：G652D, G655, 50,125...
- Central Layer Material：as
- Tube：Stainless Steel Tube
- Cable Structure：Stranding Sst Opgw Cable
- Transport Package：Steel + Drum
- Trademark：TW-SCIE
- Origin：Made in China
- HS Code：854470000
- Production Capacity：100km Per Day
Description
Layer 120%AS wire 4 2.70 mm SUS-Tube 2 2.70 mm Layer 2 20%AS wire 10 2.70 mm According to IEEE std 1138,IEC 60794-4 standards Fiber No. & Type 48 G652D Standard Diameter 13.50 mm Supporting Cross Section 97.30 mm2 Section of AS wire 97.30 mm2 Approximate mass 687.0 kg/km Rated Tensile Strength 117.0 kN Maximum Allowable Tension(40%RTS) 46.8 N/mm2 Everyday Stress(25%RTS) 29.3 N/mm2 Strain Margin Stress(70%RTS) 81.9 N/mm2 Modulus of Elasticity 162.0 GPa Thermal Elongation Coefficient 13.0 ×10-6/ºC Calculated D.C. Resistance at 20ºC 0.878 Ω/km Short-Circuit Current Capacity(40~200ºC, 0.25s) 45.3 kA2·s Ratio between Pull and Weight 17.40 km Temperature Installation -10ºC~+50 ºC Range: Transportation and Operation -40ºC~+80 ºC
Our Quality & Service:
DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:
1.Consistently meeting for product quality and performance;
2. Timely delivery of products and services to meet our customer's requirements;
3. Ensuring that our people are properly trained so that they are better able to serve our customers.
Our Certificate:
REACH
ROHS
TLC Telecom Certificate
Environmental Management System Certification
ISO9001:2000
Utility Model Patent Certificate
As professioanl manufacturer on optical fibre cables, we can not only offer you optical fibre cables with high quality and competitive price, but also the structures as your requirment. So please feel free to contact with us for cooperation and excellent service.
Tag: OPGW cable, OPGW optic fiber cable, OPGW fiber cable,OPGW factory
