Rg223/U Coaxial Cable 50 Ohm Double Shield Coaxial Cable Low Loss
Jiangsu Elesun Cable Co., Ltd.- Application：Coaxial Cable
- Conductor Material：Copper
- Cover Material：PVC Lzsh PE
- Type：Coaxial
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：RG223,U
- Wire Core Material：Silver Copper
- Certification：CE, ISO, RoHS, UL
- Brand：Elesun
- Jacket：PVC,PE,Lzsh
- Color：Black White
- Impedance：50 Ohm
- Working Temperature：-20~+80
- Transport Package：Pallet
- Specification：(112+128)*0.12
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：300km,Month
Description
RG223/U low loss coaxial cable specifications
Material of Inner Conductor
SC
Structure of Inner Conductor
1/0.9mm
Material of Insulation
solid PE
Diameter of Insulation
2.95mm
Material of Braiding
SC (Silver Copper),(112+128)*0.12mm
Material of Jacket
PVC,PE, FRPE, FRPVC
Diameter of Jacket
8.4mm
Working temp
-40ºC/80ºC
Impedance
50Ω±2
Voltage
4000V
SWR(0-2500MHz)
≤1.2
FAQQ: Can I have a sample testing before mass order?
Yes, We provide samples free and sample freight charge will be paid by customer. Sample delivery time is quick.
Q: What about the lead time of production
Usually it is 10-15days, for cables above 300KM delivery time is about 20-25 days
Q: Do you have MOQ limit for order
Normally 1KM each item, for special order less than 1KM we can check together.
Q: How about shipment way?
For samples which we choose UPS/DHL/TNT/FEDEX and for sea shipment we choose SHA or NINGBO port
Q: Is it OK to print our logo on the cable?
Yes Of course,just forward us your details before placing order.
Q: How do you solve the problem of after sale service
Quality is the priority rule in our company, we will make sure the quality before delivery and any
feedback from customer we will handle and replace asap.
