Overhead Conductors AAC/ AAAC/ ACSR/ Acar/ Accc Bare Conductors
YIFANG ELECTRIC GROUP INC.- Type：Bare
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum
- Sheath Material：Crosslinking
- Insulation Material：XLPE
Base Info
- Material Shape：Round Wire
- Certification：ISO9001, CE, UL, CCC
- Brand：Yifang
- Transport Package：Wooden Drum
- Origin：China
- Production Capacity：500km,Month
Description
Code name
Nominal aluminium area
Stranding and wire diameter
Sectional area of aluminium
Total sectional area
Approx. overall diameter
Approx. mass
Calculated D.C. resistance at 20oC
Calculated breaking load
Al
Steel
mm2
No./mm
mm2
mm2
mm
kg/km
Ω/km
kN
RABBIT
50
6/3.35
1/3.35
52.88
61.7
10.05
214
0.5426
18.35
DOG
100
6/4.72
7/1.57
105
118.5
14.15
394
0.2733
32.7
WOLF
150
30/2.59
7/2.59
158.1
194.9
18.13
726
0.1828
69.2
DINGO
150
18/3.35
1/3.35
158.7
167.5
16.75
506
0.1815
35.7
LYNX
175
30/2.79
7/2.79
183.4
226.2
19.53
842
0.1576
79.8
ZEBRA
400
54/3.18
7/3.18
428.9
484.5
28.62
1621
0.0674
131.9
AAC Technical Characteristics Based on Standard DIN 48201 / DIN EN50182
Code number
Area
Number of wires
Wire diameter
Conductor diameter
Linear mass
Rated strength
D.C. resistance at 20oC
mm2
No.
mm
mm
kg/km
kN
Ω/km
16
15.9
7
1.7
5.1
43.4
3.02
1.7986
25
24.2
7
2.1
6.3
66.3
4.36
1.1787
35
34.4
7
2.5
7.5
93.9
6.01
0.8317
50
49.5
7
3
9
135.2
8.41
0.5776
50
48.3
19
1.8
9
132.9
8.94
0.5944
70
65.8
19
2.1
10.5
180.9
11.85
0.4367
95
93.3
19
2.5
12.5
256.3
16.32
0.3081
120
117
19
2.8
14
321.5
19.89
0.2456
150
147.1
37
2.25
15.8
405.7
26.48
0.196
185
181.6
37
2.5
17.5
500.9
31.78
0.1588
240
242.5
61
2.25
20.3
671.1
43.66
0.1193
300
299.4
61
2.5
22.5
828.5
52.4
0.0966
AAAC Technical Characteristics Based on Standard BS 3242
Code name
Nominal aluminium area
Stranding and wire diameter
Sectional area
Approx. overall diameter
Approx. mass
Calculated D.C. resistance at 20oC
Calculated breaking load
mm2
No./mm
mm2
mm
kg/km
Ω/km
kN
ALMOND
25
7/2.34
30.1
7.02
82
1.094
8.44
CEDAR
30
7/2.54
35.47
7.62
97
0.9281
9.94
FIR
40
7/2.95
47.84
8.85
131
0.688
13.4
HAZEL
50
7/3.30
59.87
9.9
164
0.5498
16.8
OAK
100
7/4.65
118.9
13.95
325
0.2769
33.3
ASH
150
19/3.48
180.7
17.4
497
0.183
50.65
ELM
175
19/3.76
211
18.8
580
0.1568
59.1
UPAS
300
37/3.53
362.1
24.71
997
0.09155
101.5
About us
Zhengzhou Yifang Cable Co., Ltd is a large joint-stock, hi-tech enterprise established in 2001. We are specialized in wires & cables, including designment, production and sales. Located in Zhengzhou, China, our factory's position is extremely advantageous.
There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.
Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire),flame retardant mining cable, etc
We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
