• Model NO.：Mining Cable
• Material Shape：Round Wire
• Range of Application：Underwater
• Certification：ISO9001, CE, CCC, KEMA
• Brand：Yifang
• Transport Package：Coil, Drum, etc
• Specification：95mm2
• Trademark：YIFANG CABLE
• Origin：Zhengzhou, Henan, China
• HS Code：8544492100
• Production Capacity：500km,Month

HAR CodeIECDescriptionVoltage DesignCores H05RR-F60245IEC 53(YZ)/YZOrdinary rubber sheathed cord300/500V2~6  H05RN-F60245    IEC 57(YZW)/YZW  Ordinary polychloroprene or other equivalent synthetic elastomer sheathed cord300/500V  2~6  H07RN-F60245            IEC 66(YCW)/YCHeavy polychloroprene or other equivalent synthetic elastomer sheathed flexible cable450/750V
1~5, 3+1/3+2/4+1  H01N2-D60245 IEC 81(YH)Rubber sheathed arc-welding electrode cable100/100V  10-12060245
IEC 82(YHF)polychloroprene or other equivalent synthetic elastomer sheathed arc-welding electrode cable100/100V  10-120



The Product Model & Specification

Core no. x Nominal sectional area (mm2)

Pcs./Wire dia. (mm)

Insulation thickness(mm)

Sheath thickness

(mm)

Average outer dia.(mm)

Weight Reference kg/km

Max DC resistance of conductor at20°C

Ω/km

Min.

Max.

1×1.5

30/0.25

0.8

1.4

5.7

7.1

76

13.3

1×2.5

49/0.25

0.9

1.4

6.3

7.9

98

7.98

1×4

56/0.30

1.0

1.5

7.2

9.0

130

4.95

1×6

84/0.30

1.0

1.6

7.9

9.8

174

3.30

1×10

84/0.40

1.2

1.8

9.5

11.9

251

1.91

1×16

126/0.40

1.2

1.9

10.8

13.4

330

1.21

1×25

196/0.40

1.4

2.0

12.7

15.8

475

0.780

1×35

276/0.40

1.4

2.2

14.3

17.9

605

0.554

1×50

396/0.40

1.6

2.4

16.5

20.6

828

0.386
