• Model NO.：PND315-1250
• Transport Package：Industral Packing
• Trademark：ONEREEL
• Origin：China
• HS Code：7326901000
• Production Capacity：1000PCS,Month

Basic Info.

Model NO. PND315-1250 Transport Package Industral Packing Trademark ONEREEL Origin China HS Code 7326901000 Production Capacity 1000PCS/Month

Product Description

Name: Steel Cable Spool for Copper Wire

In accordance with GB4004-83, JB/T7600.3-94 and DlN46395 standards, the product is made of common carbon steel Q235 thick plate through assembly and welding, and machine finishing. The product has high rigidity of bobbin and high precision. Through dynamic test, the product has stable operation at high speed, and can be used for high-speed drawing-wire machine and wire stranding machine.

Serial Number	Specification Model	Lateral Plate Diameter D1	Major Diameter D2	Axle Hole Diameter D4	Carrying Hole Diameter D5	Center Distance E of Axle Hole and Carrying Hole	External Width L1	Internal Width L2
1	400	400	224/250 280	125/127	28	100	265 300	224 250
2	500	500	280/315 355	125/127	28	100	300 375	250 315
3	560	560	315/355 400	125/127	28	100	355 425	280 355
4	630	630	355/400 450	125/127	28	100	375 475	315 400
5	710	710	400/450 500	250	40	170	425 530	355 450
6	800	800	450/500 560	250	40	170	475 600	400 500
7	1000	1000	560/630 710	250	50	250	750	630
8	1250	1250	710/800 900	250	50	250	950	800



Our main products
Plastic bobbin
1.For process and recycle usage.
2.Superfine wire bobbin
3.Packing and delivery bobbin
Metal reel:
1.Corrugated reel for process
2.Punching type steel reel
3.Double layer high speed steel reel
4.Flat-plate type steel reel for high speed machine
5.Enhanced welding-type steel reel
6.Aluminum reel


FAQ

Frequently Asked Questions
1) What is your MOQ?
Usually our MOQ is upon your spools type,different spools with different MOQ. But we accept lower quantity for your trial order.
2) Can I get samples ?
According to spool model and material ,we will advice.
3) How long is the sample LEAD TIME?
For existing samples, it takes 2-3 days. If no stock,we will advice lead time.
4) Can you develop new products?
Yes, we have new products developing ability and we are good at developing new mold
5) How much is the freight charge?
 It depends on spool package volume,
if  small qty,volume and urgent goods,we may advise DHL or other couriers' charge for your check.
if volume bigger and by seaway suitable,we provide FOB or CIF price to you.
6) What format of the file do you need if I want my own design?
We have our own mould workshop and can provide spool or other plastic product developing and injection service.
 You can provide JPG, PDF,dwg files for check.

Note:  If you don't find the exact products you need, pls feel free to contact us.
After we checked your requirements, we will provide best offer asap.
