Lfmsgssgo Light Marine Telecommunications Cable 250V Double Screened

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Telecomunication
  • Conductor Material：Copper
  • Sheath Material：Crosslinked Olefine Compound
  • Insulation Material：Polyalkene Compound

Base Info

  • Model NO.：LFMSGSSGO Cable
  • Material Shape：Round Wire
  • Range of Application：Telecomunication
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multiple core
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemLFMSGSSGO CableConductorClass 5 flexible copperInsulationPolyalkene compoundScreen1Plain copper wire braidScreen2Plain copper wire braidOuter SheathCrosslinked olefine compoundNominal VoltageU0/U: 250/250VTest voltage2000 VTemperature RangeMax. operating temperature of the conductor 90 °C
Ambient temperature for fix installation min. -30 °C
Laying temperature min. -15 °CColorOptionalCertificationCEApplicationFor fixed installation on ships in all locations and on open decks. The definitions for installation in BV 3400 apply. The cables are certified from the Bundesamt für Ausrüstung, Informationstechnik und Nutzung der Bundeswehr (BAAINBw).
