Thermoplastic Insulated Ant1001 Cable Unshielded Towline Cable

Shanghai Aein Wire & Cable Co., Ltd.

Type：Insulated
Conductor Type：Stranded
Application：Fixed Installation
Conductor Material：Copper
Sheath Material：Special Elastomer Compound
Insulation Material：Special Thermoplastic Compound

Base Info

Model NO.：ANT1001 Cable
Material Shape：Round Wire
Range of Application：Oil-Resistant
Certification：ISO9001, CE, UL, RoHS
Brand：Aein
Transport Package：Optional
Specification：Multi Core
Trademark：AEIN
Origin：Shanghai
HS Code：8544492100

Description

ItemANT1001 Cable Unshielded Towline Cable ConductorFine bare copper (as client's required)InsulationSpecial thermoplastic compound (as client's required)SheathSpecial elastomer compound (as client's required)Rated Voltage300/300V &300/500VTest Voltage1500V &2000VOperating TemperatureFlexible installations: -10 ºC~+70ºC
Fixed installations: -30ºC~+70ºCMinimum bending radiusFlexible installations:7.5 × cable diameter
Fixed installations: 5 x cable diameter ColorOptionalApplicationThe cable is suitable for modern machining, machine tool industry, roboticsand machinery production, and other places where high flexibility isrequired. Particularly suitable for flexible applications where frequentbending and slow movement under moderate mechanical loads.
