Hfc 75 Ohm Trunk Cable Qr 500 Coaxial Cable

Hangzhou Softel Optic Co., Ltd.
  • Application：Coaxial Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PE
  • Type：Coaxial Cable
  • Material Shape：Round Wire
  • Certification：CE, ISO

Base Info

  • Model NO.：QR500
  • Model：Qr500
  • Brand：Softel
  • Product Name：Hfc 75 Ohm Trunk Cable Qr 500 Coaxial Cable
  • Dielectric Material：Foam PE
  • Dielectric Nom. Dia：11.43mm
  • out Conductor Material：Al
  • out Conductor No. Thick：0.35mm,0.5mm
  • Transport Package：Standard Export Package
  • Specification：84X57X40cm
  • Trademark：SOFTEL
  • Origin：Hangzhou, Zhejiang, China

Description

 500500JCA500 MessengerConductorMaterialBC/CCABC/CCABC/CCANom. Dia.2.77mm2.77mm2.77mmDielectricMaterialFoam PEFoam PEFoam PENom. Dia.11.43mm11.43mm11.43mmOut conductorMaterialAIAIAINo. Thick0.35mm/0.5mm0.35mm/0.5mm0.35mm/0.5mmNom. Dia.12.7mm12.7mm12.7mmJacketMaterialPEPEPENom. Thick.0.76mm0.76mm0.76mmNom. Dia.14.22mm14.22mm14.22mmMessenger //2.77mm
Nominal Impedance(ohm)75±3Nominal Velocity of Propagation(%)87Nominal Capacitance(pF/m)55±3.0Sparker Test(VAC)4000SRL(db)30-470≥20470-1000≥18 Frequency(MHz)Maximum(dB/100ft)Maximum(dB/100m)Attenuation
[68°F(20ºC)]50.160.52550.541.772111.093.583001.314.33501.434.694001.535.024501.635.355001.825.977502.167.098652.347.6810002.528.27
Hfc 75 Ohm Trunk Cable Qr 500 Coaxial CableHfc 75 Ohm Trunk Cable Qr 500 Coaxial Cable
Company information
 Hfc 75 Ohm Trunk Cable Qr 500 Coaxial Cable FAQ

1. What are the payment terms that you support?
Usually, we accept T/T, PayPal, Western Union, and Alibaba Trade Assurance. You can select the terms of payment which is more convenient for you.

2. What about the lead time?
Usually, if there's stock, we ship the goods within 3~5 working days after the deposit is confirmed. If it is out of stock, the lead time depends.

3. How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, and UPS and so on, while the goods have high weight and volume, we suggest using air or sea shipment.

4. How can I place an order?
(1) Negotiation is agreed upon for the product price and specifications.
(2) The Proforma invoice will be sent for confirmation.
(3) After the agreement on the proforma invoice, the customer makes the deposit.
(4) Manufacturing will be started as soon as the payment is confirmed by our bank.
(5) Ship out the goods within the agreed delivery deadline.

5. Can you do OEM for us?
Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.

6. How about the Warranty?
There are 12 months for the warranty.
While the warranty is not responsible for those broken by violence or updated with other brands.
