Enameled Manganin Wire/Low Resistance Alloy Wire

Shanghai Tankii Alloy Material Co., Ltd.
  • Insulation Level：C
  • Certification：ISO9001, CE, CCC, RoHS
  • Brand：TANKII
  • Application：Overhead, Heating
  • Shape：Round Wire
  • Conductor Material：Alloy Wire

Base Info

  • Model NO.：Manganin
  • Serves：Samll Order Accepted
  • Type：Insulated
  • Conductor Type：Solid
  • Transport Package：in Spool
  • Specification：0.02-1.2mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：85441100
  • Production Capacity：2000 Tons,Year

Description

ROHS DirectiveCdPbHgCr2~311~130.5(max)microBal-NDNDNDND
Mechanical PropertiesTemp Coefficient of Resistance at 20 ºC-2~+2α×10-6/ºC(Class0)-3~+5α×10-6/ºC(Class1)-5~+10α×10-6/ºC(Class2)Melting Point1450ºCTensile Strength(Hard)635 Mpa(min)Tensile Strength,N/mm2   Annealed,Soft340~535Elongation15%(min)EMF vs Cu, μV/ºC (0~100ºC)1Micrographic Structure austeniteMagnetic PropertynonMicrographic StructureFerriteMagnetic PropertyMagnetic
Application of Manganin
Manganin foil and wire is used in the manufacture of resistor, Particularly ammeter shunt, because of its virtually zero temperature coefficient of resistance value and long term stability.
