Leaky Feeder Cable of Wireless Voice to Undergound Mines
ZHEJIANG LIBO INDUSTRIAL CO., LTD.- Application：Local Communication Cable, Coaxial Cable, Fiber Optic Cable, Long Distance Symmetric Cable, RF Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PE
- Type：Cat 6
- Material Shape：Hollow Line
- Conductor Type：Stranded
Base Info
- Model NO.：Leaky Feeder Cable
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, CCC, UL
- Model：MHYV-xx
- Brand：FUJI
- Msha Certificate：Bare Copper Wire Braiding
- Low Smoke：Leaky Feeder Cable
- Transport Package：Plate
- Specification：CE, ROSHS, SGS
- Trademark：Libo cable
- Origin：Zhejiang, China
- HS Code：854420
- Production Capacity：3000kms,Month
Description
Inner conductor
2.31mm bare copper
Dielectric
9.50mm
Outer conductor
16x0.6 bare copper wire
Outer jacket
15.0mm+/-0.2mm
Frequency
5 to 500MHZ
impedance
75 ohms
Attenuation @160 MHZ
4.2dB/100m
DC resistance inner conductor
<4.5 ohm/km
DC resistance outer conductor
<4.1 ohm/km
capacitance
54 pF/m
Insulation resistance
>10.4m ohm/km
MIN. bend radius
150mm
Operating temperature
-40 to +70 centigrade
Competitive Advantage:
Libo cable was established in 1994, it covers over 340,000 square meters on our operating area.
Libo cable has a stable workforce and engineering team, our production and testing procedures are all strictly follow requirement of ISO9000, and ISO14000.
Libo cable is equipped with a Provincial-level Research and Development Center; we offer OEM and ODM services.
Over 10 years of experience on leaky feeder cable, big market share in oversea leaky feeder cable industry.
