- Model NO.:Primary UD Cable
- Wire Core Material:Aluminum 1350 Wire
- Certification:ISO, CCC
- Model:Primary Ud Cable
- Brand:Boan
- Rated Voltage:35 Kv
- Size Range:1,0-1000 AWG or Kcmil
- Insulation Level:100% or 133%
- Neutral Level:1,3 or Full
- Neutral Type:Copper Wire
- Size of Neutral:14,10,9 AWG
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn or OEM
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
1/3 Neutral | Full Neutral |
Size AWG or kcmil | Number of Strands | Nominal OD Over Insulation in | Number of Wires | Size AWG | Jacket Thickness mil | Approximate Outside Diameter in | Approximate Net Weight lb/kft | Size AWG or kcmil | Number of Strands | Nominal OD Over Insulation in | Number of Wires | Size AWG | Jacket Thickness mil | Approximate Outside Diameter in | Approximate Net Weight lb/kft |
Aluminum 100% Insulation Level (345 mil) |
1/0 | 1 | 1.06 | 6 | 14 | 50 | 1.38 | 858 | 1/0 | 1 | 1.06 | 16 | 14 | 50 | 1.38 | 979 |
1/0 | 19 | 1.10 | 6 | 14 | 50 | 1.42 | 895 | 1/0 | 19 | 1.10 | 16 | 14 | 50 | 1.42 | 1015 |
2/0 | 19 | 1.14 | 7 | 14 | 50 | 1.47 | 971 | 2/0 | 19 | 1.14 | 20 | 14 | 50 | 1.47 | 1127 |
3/0 | 19 | 1.19 | 9 | 14 | 50 | 1.52 | 1070 | 2/0 | 19 | 1.14 | 13 | 12 | 50 | 1.50 | 1167 |
4/0 | 19 | 1.25 | 11 | 14 | 50 | 1.57 | 1184 | 3/0 | 19 | 1.19 | 25 | 14 | 50 | 1.52 | 1263 |
250 | 37 | 1.30 | 13 | 14 | 80 | 1.69 | 1358 | 3/0 | 19 | 1.19 | 16 | 12 | 50 | 1.55 | 1300 |
350 | 37 | 1.40 | 18 | 14 | 80 | 1.79 | 1604 | 4/0 | 19 | 1.25 | 32 | 14 | 50 | 1.57 | 1437 |
500 | 37 | 1.53 | 25 | 14 | 80 | 1.95 | 1989 | 4/0 | 19 | 1.25 | 20 | 12 | 50 | 1.61 | 1468 |
500 | 37 | 1.53 | 16 | 12 | 80 | 1.99 | 2036 | 4/0 | 19 | 1.25 | 13 | 10 | 80 | 1.71 | 1592 |
750 | 61 | 1.74 | 24 | 12 | 80 | 2.19 | 2628 | 250 | 37 | 1.30 | 25 | 12 | 80 | 1.73 | 1716 |
750 | 61 | 1.74 | 15 | 10 | 80 | 2.24 | 2684 | 250 | 37 | 1.30 | 16 | 10 | 80 | 1.77 | 1772 |
1000 | 61 | 1.89 | 31 | 12 | 80 | 2.34 | 3139 | 350 | 37 | 1.40 | 32 | 12 | 80 | 1.83 | 2038 |
1000 | 61 | 1.89 | 20 | 10 | 80 | 2.38 | 3217 | 350 | 37 | 1.40 | 20 | 10 | 80 | 1.87 | 2084 |
1000 | 61 | 1.89 | 16 | 9 | 80 | 2.41 | 3260 | 350 | 37 | 1.40 | 16 | 9 | 80 | 1.89 | 2119 |
- | - | - | - | - | - | - | - | 500 | 37 | 1.53 | 29 | 10 | 80 | 2.03 | 2667 |
- | - | - | - | - | - | - | - | 750 | 61 | 1.74 | 28 | 8 | 80 | 2.29 | 3661 |
- | - | - | - | - | - | - | - | 1000 | 61 | 1.89 | 37 | 8 | 80 | 2.44 | 4483 |
Aluminum 133% Insulation Level (420 mil) |
1/0 | 19 | 1.25 | 6 | 14 | 50 | 1.57 | 1076 | 1/0 | 19 | 1.25 | 16 | 14 | 50 | 1.57 | 1196 |
2/0 | 19 | 1.29 | 7 | 14 | 50 | 1.62 | 1157 | 2/0 | 19 | 1.29 | 20 | 14 | 80 | 1.68 | 1380 |
3/0 | 19 | 1.34 | 9 | 14 | 80 | 1.73 | 1331 | 2/0 | 19 | 1.29 | 13 | 12 | 80 | 1.71 | 1424 |
4/0 | 19 | 1.40 | 11 | 14 | 80 | 1.79 | 1454 | 3/0 | 19 | 1.34 | 25 | 14 | 80 | 1.73 | 1524 |
250 | 37 | 1.45 | 13 | 14 | 80 | 1.84 | 1571 | 3/0 | 19 | 1.34 | 16 | 12 | 80 | 1.76 | 1566 |
350 | 37 | 1.56 | 18 | 14 | 80 | 1.98 | 1876 | 4/0 | 19 | 1.40 | 32 | 14 | 80 | 1.79 | 1707 |
500 | 37 | 1.68 | 25 | 14 | 80 | 2.11 | 2235 | 4/0 | 19 | 1.40 | 20 | 12 | 80 | 1.82 | 1743 |
500 | 37 | 1.68 | 16 | 12 | 80 | 2.14 | 2285 | 4/0 | 19 | 1.40 | 13 | 10 | 80 | 1.86 | 1805 |
750 | 61 | 1.89 | 24 | 12 | 80 | 2.34 | 2902 | 250 | 37 | 1.45 | 25 | 12 | 80 | 1.88 | 1933 |
750 | 61 | 1.89 | 15 | 10 | 80 | 2.39 | 2963 | 250 | 37 | 1.45 | 16 | 10 | 80 | 1.92 | 1992 |
1000 | 61 | 2.04 | 16 | 9 | 80 | 2.56 | 3560 | 350 | 37 | 1.56 | 32 | 12 | 80 | 2.01 | 2314 |
- | - | - | - | - | - | - | - | 350 | 37 | 1.56 | 20 | 10 | 80 | 2.05 | 2365 |
- | - | - | - | - | - | - | - | 350 | 37 | 1.56 | 16 | 9 | 80 | 2.08 | 2403 |
- | - | - | - | - | - | - | - | 500 | 37 | 1.68 | 29 | 10 | 80 | 2.18 | 2920 |
