Copper Conductor Nylon Sheath Thhn Cable
YIFANG ELECTRIC GROUP INC.- Type：Insulated
- Conductor Type：Stranded
- Application：Buliding and Indoor
- Conductor Material：Copper
- Sheath Material：Nylon
- Insulation Material：PVC
Base Info
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, CCC
- Brand：Yifang
- Insulation Color：Yellow,Green, Red, Black, Blue, Brown, Grey etc.
- Voltage：450,750V
- Transport Package：Wooden Drums, Plastic Roll etc.
- Origin：China
- HS Code：8544492100
- Production Capacity：110, 000km Per Year
Description
Nominal
sectional area
mm2
Conductor
No/Dia.
mm
Nominal
Insulated thick
mm
Max overall
Dia.
mm
Condcutor
Resistance at
20
Min insulated
resistance at
70MΩ/km
Weight
Kg/km
Cu
Al
Cu
Al
1.5
1/1.38
0.7
3.3
12.1
-
0.011
19.2
-
1.5
7/0.52
0.7
3.5
12.1
-
0.010
20.6
-
2.5
1/1.78
0.8
3.9
7.41
11.8
0.010
30.8
15.0
4
1/2.25
0.8
4.4
4.61
7.39
0.0085
45.5
21.0
6
1/2.76
0.8
4.9
3.08
4.91
0.0070
65.0
29.0
10
7/1.35
1.0
7.0
1.83
3.08
0.0065
110.0
52.0
16
7/1.70
1.0
8.0
1.15
1.91
0.0050
170.0
70.0
25
7/2.14
1.2
10.0
0.727
1.20
0.0050
270.0
110.0
35
7/2.52
1.2
11.5
0.524
0.868
0.0040
364.0
150.0
50
19/1.78
1.4
13.0
0.387
0.641
0.0045
500.0
200.0
70
19/2.14
1.4
15.0
0.268
0.443
0.0035
688.0
269.0
95
19/2.52
1.6
17.5
0.193
0.320
0.0035
953.0
360.0
120
37/2.03
1.6
19.0
0.153
0.253
0.0032
1168.0
449.0
150
37/2.25
1.8
21.0
0.124
0.206
0.0032
1466.0
551.0
185
37/2.52
2.0
32.5
0.099
0.164
0.0032
1808.0
668.0
* We can design and produce according to client's requirement.
