Tml T-F Cable for Drinking and Industrial Water Medium Mechanical Requirements

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Installation
  • Conductor Material：Copper
  • Sheath Material：Epr
  • Insulation Material：Epr or Vpe

Base Info

  • Model NO.：TML T-F
  • Material Shape：Round Wire
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemTML T-F Cable for Medium Mechanical Requirements ConductorBare copper strandInsulationBased on EPROuter SheathBased on EPR or VPEFillerOptionalNominal VoltageUo/U: 450/750 VOperat. temp. fixed min/max -40 °C / +60 °COperat. temp. moved min/max -25 °C / +60 °CTemp. at conductor+90°CColorOptionalCertificationCESpecial Features• TML T-RD: rated voltage up to 0.6/1 kV when protected and fixed laying in pipes of well systems.
• Free from lacquer damaging substances and silicone (during production)
• Suitable for permanent use in drinking water up to max. 400 m diving depthApplicationFor permanent use in water to connect electrical equipment such as submerged pump motors. Suitable for drinking and industrial water and for medium mechanical requirements.
