Flexible Cable Gold Plated Copper Conductor 006 Silicone Extra Flexible Wire with 8AWG Dw02
Dongguan Dewei Wire Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Copper
- Insulation Material：Silicone Rubber
- Material Shape：Round Wire
Base Info
- Model NO.：8AWG 006
- Certification：ISO9001, RoHS
- Brand：Dewei Wire
- Silicone Insulated Extra- Flexible Cr：8AWG
- Transport Package：100m,Coil, 5 Coils in a Box
- Specification：006, ISO9001, ROHS
- Trademark：DEWEI
- Origin：Dongguan, China
- HS Code：8544492100
- Production Capacity：100000m,Day
Description
Overview
Con.of conductor. Diameter Thickness of insulator Over diameter Packing NO/mm mm mm mm mt/coils 28# 28/0.06 0.36 0.5 1.35 500 26# 42/0.06 0.45 0.5 1.50 500 24# 80/0.06 0.58 0.5 1.60 200 22# 120/0.06 0.72 0.5 1.70 200 20# 195/0.06 0.92 0.55 1.85 200 18# 294/0.06 1.19 0.6 2.30 200 16# 483/0.06 1.47 0.7 3.00 200 14# 707/0.06 1.85 0.9 3.50 200 12# 1062/0.06 2.29 1.00 4.48 200 10# 1780/0.06 2.95 1.50 5.20 100 8# 2960/0.06 3.75 1.50 6.00 100 1,All raw material we selected the high quality one.
2,Professional & Skilful workers care every details in handling the producing.
3,Quality Control Department specially responsible for quality checking in each process.
