• Model NO.：VV
• Wire Core Material：Copper
• Model：VV22
• Brand：Yifang
• Core Identification：Red,Yellow,Black,Blue
• Transport Package：Wooden and Steel Drum
• Specification：Iec60502
• Trademark：Yifang
• Origin：Zhengzhou, Henan
• HS Code：8544492100
• Production Capacity：500km,Month

TypeNo. of CoreNominal Cross-section of conductor  mm2Cu(Al)/XLPE/PVC(PE)
Cu(Al)/XLPE/ATA/PVC(PE)
Cu(Al)/XLPE/AWAPVC(PE)11.5-1000Cu(Al)/XLPE/STA/PVC(PE)

Cu(Al)/XLPE/SWA/PVC(PE)2, 3, 4, 51.5-4003+1, 4+1, 3+22.5-400
3. Cross-section area of neutral conductor
    In 3+1 core and 3+2 cores should conform to specification of following table:
 Nominal Cross-sectionMain core2.5461016253550Neutral core1.52.54610161625
 Nominal Cross-sectionMain core7095120150185240300400Neutral core3550707095120150185
4. Main technical Characteristics of Cable
   1) D.C .Resistance: Conductor resistance of finished cable per kilometer at 20oC is not more than the following:
 Nominal Cross-section  mm2152.546101625Cu core12.17.414.613.081.831.150.727Al core18.112.17.414.613.081.911.20Nominal Cross-section  mm235507095120150185Cu core0.5240.3870.2680.1930.1530.1240.0991Al core0.8680.6410.4430.3200.2530.2060.164Nominal Cross-section  mm22403004005006308001000Cu core0.07540.06010.04700.03660.02830.02210.0176
  2) Voltage Test
     Each drum of finished cable should withstand power frequency voltage 3.5kv for 5 minutes, the insulation is not breakdown.

  3) Service conditions and parameters of cable
     The cable is applied to fixed insulation for rated voltage 0.6/1kv of power transportation and distribution line.
     Max. rated temperature of conductor nominal operating 90oC.
     Short circuit: max. for 5 sec. 250oC.
     The cable can be laid without drop retriction, and the environment temperature shall not be lower than 0oC.
