Ordinary Duty Applications and Supplying Appliances H05bq-F Cable 300/500V

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PUR
  • Insulation Material：Epr
  • Material Shape：Round Wire

Base Info

  • Model NO.：H05BQ-F Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemH05BQ-F Cable ConductorClass 5 flexible plain copper wiresInsulationCross linked EPR (Ethylene propylene)Outer sheathPUR (Polyurethane)Core NumberMulticores (As client's requirement)Temperature rangeOperating: -40ºC to +90ºC

Maximum Short Circuit Temperature: 250ºC (Max. 5 seconds)Rated voltageUo/U 300/500VColorOptionalApplicationFor use in domestic premises, kitchen and offices. for ordinary duty applications and supplying appliances where cables are subject to low mechanical stresses (e.g. vacuum cleaners, cooking appliances, soldering irons, toasters, domestic portable tools and hand held inspection lamps). Use outdoors for temporary periods of short duration.
