Awm Style 1091 Stranded Fluoroplastic High Temperature Cable Wire
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：The Wiring for Appliance
- Conductor Material：Copper
- Insulation Material：FEP
- Material Shape：Round Wire
Base Info
- Model NO.：UL1091
- Range of Application：Heat Resistance
- Certification：ISO9001, UL, RoHS, Reach
- Brand：Bort
- Conductor：Stranded Copper Conductor
- Sample：Conventional Sample Free
- Producing Experience：10 Years
- No. of Cores：Single Core
- Colors：Could Be Customized Color
- Delivery Time：in 7-10days
- Packing：100m,Roll, 305m,Roll, Wrap Plastic Film Packaging
- Company Type：Manufacturer
- Service：OEM, ODM
- Transport Package：100m,Roll, 305m,Roll, Wrap Plastic Film Packaging
- Trademark：Bort
- Origin：China
- Production Capacity：300000km
Description
Conductor resistance 20ºC
(Ω/KM)Nom. Min. Nom. Tol. 10 37/0.42 2.94 0.35 0.33 3.60 ±0.15 3.54 12 37/0.374 2.62 0.35 0.33 3.32 ±0.15 5.64 14 19/0.361 1.85 0.35 0.33 2.60 ±0.10 8.96 16 19/0.287 1.50 0.35 0.33 2.20 ±0.10 14.60 18 19/0.235 1.18 0.35 0.33 1.90 ±0.10 23.20 20 19/0.19 0.95 0.35 0.33 1.65 ±0.10 36.70 22 19/0.15 0.76 0.35 0.33 1.45 ±0.10 59.40 24 7/0.2 0.61 0.35 0.33 1.30 ±0.10 94.20 26 7/0.16 0.48 0.35 0.33 1.20 ±0.10 150.00 28 1/0.32 0.320 0.35 0.33 1.02 ±0.10 227.00 30 1/0.254 0.254 0.35 0.33 0.96 ±0.10 361.00
(Ω/KM)
