Covered Conductors Type CCT Alu XLPE Covered Aerial Cable AS/NZS3675
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：Crosslinking
- Material Shape：Round Wire
Base Info
- Model NO.：covered conductor
- Wire Core Material：AAAC,ACSR
- Certification：ISO, CCC
- Model：CCT Cable
- Brand：Hongda Cable
- Voltage Rating：6.35,11kv, 12,20kv, 18,30kv
- Standard：AS,NZS3675
- Sheath：XLPE Compound
- Transport Package：Steel & Wooden Drum
- Specification：1.6*1.1
- Trademark：Hongda Cable
- Origin：Made in China
- HS Code：8544601200
- Production Capacity：600km,Month
Description
- Conductor material
- Conductor cross-section
Products
| Name | Conductor material | Conductor cross-section (mm²) | Average insulation thickness (mm) |
|---|---|---|---|
| CCT 19/33kV | aluminum alloy | 80 | 8.0 |
| CCT 19/33kV | aluminum alloy | 120 | 8.0 |
| CCT 19/33kV | aluminum alloy | 180 | 8.0 |
| CCT 12.7/22kV | aluminum alloy | 80 | 5.5 |
| CCT 12.7/22kV | aluminum alloy | 120 | 5.5 |
| CCT 12.7/22kV | aluminum alloy | 180 | 5.5 |
| CCT 6.35/11kV | aluminum alloy | 40 | 3.4 |
| CCT 6.35/11kV | aluminum alloy | 80 | 3.4 |
| CCT 6.35/11kV | aluminum alloy | 180 | 3.4 |
| CCT 6.35/11kV | aluminum alloy | 240 | 3.4 |
| 19/3.5mm CCT Grey 6.35/11kV | aluminum alloy | 180 | 3.4 |
| 7/3.75mm CCT Grey 6.35/11kV | aluminum alloy | 80 | 3.4 |
| 7/2.75mm CCT Grey 6.35/11kV | aluminum alloy | 40 | 3.4 |
| 7/4.75mm CCT Grey 6.35/11kV | aluminum alloy | 120 | 3.4 |
Please contact us for technical support with the right cable selection for your power distribution projects and to discuss your maintenance or project specific requirements. We provide tailored solutions for this cable range which include storage, cutting to length, and 2 days collection as standard.
Any problem and inquiry pls contact with Vivian Yuan.
