1000V Flat Flexible Cable, Copper

YIFANG ELECTRIC GROUP INC.
  • Type：Insulated
  • Conductor Type：Flexible
  • Application：Overhead
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：4x6mm2 BM11
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, CCC, RoHS, VDE
  • Brand：Yifang
  • Option Insulation：Epr Insulation
  • Option Sheath：CPE Sheath
  • Transport Package：Wooden or Wooden-Steel Drum
  • Specification：4x6mm2 12x1.5mm2
  • Trademark：Yifang Cable
  • Origin：Zhengzhou, China
  • HS Code：8544601200
  • Production Capacity：300km,Month

Description

TypeCross section


(mm2)thickness
of
Insualtion
(mm)Thickness of sheath
(mm)Insulation
Resistance
at 70
(MΩ.km)Conductor
DC Resistance at 20
(Ω/km)Outer Size


   (mm)Approx. Weight

(Kg/km)e1e2e3TVVB
300/500V30X0.750.42.01.21.4≥0.011≤26.041.0X9.064036X0.750.42.01.21.4≥0.011≤26.045.0X9.577540X0.750.42.01.21.4≥0.011≤26.052.5X9.084042X0.750.42.01.21.4≥0.011≤26.051.0X9.590048X0.750.42.01.21.4≥0.011≤26.057.0X9.5101060X0.750.42.01.21.4≥0.011≤26.069.0X9.51250TVVB
300/500V30X1.00.62.01.41.6≥0.010≤19.549.0X10.590036X1.00.62.01.41.6≥0.010≤19.554.0X11.5105040X1.00.62.01.41.6≥0.010≤19.563.0X10.5115042X1.00.62.01.41.6≥0.010≤19.561.0X11.5110048X1.00.62.01.41.6≥0.010≤19.569.0X11.5135060X1.00.62.01.41.6≥0.010≤19.584.0X11.51690
