• Model NO.：H05VV-F PVC Insulated and Jacketed Flat Cable
• Material Shape：Flat Wire
• Range of Application：Flame Retardant
• Certification：UL, RoHS, VDE
• Brand：Bort
• Packaging：1000FT,Spool
• Weight：About 1kg,1000FT
• Color Available：Any Colors
• Delivery Time for Samples：3-5days
• Delivery Time for Mass Production：7-10days
• Appliance：Electrical Instrument, Power & Automatic Device
• Warranty Time：at Least 10years for Proper Use
• Standard of Production：RoHS & Reach
• Factory Management Standard：ISO9001:2008
• Annual Capacity：300,000kms
• Transport Package：Coiled in The Plastic Spool
• Specification：22AWG
• Trademark：BoRt
• Origin：Zhangzhou, China
• HS Code：8544492900
• Production Capacity：300000kms

Basic Info.

Model NO. H05VV-F PVC Insulated and Jacketed Flat Cable Material Shape Flat Wire Range of Application Flame Retardant Certification UL, RoHS, VDE Brand Bort Packaging 1000FT/Spool Weight About 1kg/1000FT Color Available Any Colors Delivery Time for Samples 3-5days Delivery Time for Mass Production 7-10days Appliance Electrical Instrument, Power & Automatic Device Warranty Time at Least 10years for Proper Use Standard of Production RoHS & Reach Factory Management Standard ISO9001:2008 Annual Capacity 300,000kms Transport Package Coiled in The Plastic Spool Specification 22AWG Trademark BoRt Origin Zhangzhou, China HS Code 8544492900 Production Capacity 300000kms

Product Description

TUV Approved EU EN50618 Standard 2.5Mm2 H05vv F Power Cable

H05VV-F Application Scope :
Available for external & internal wiring of electrical instrument, power device & automatic device without forcible traction. Without direction, at times for movable wiring.

H05VV-F Cable structure:
Conductor: Stranded bare copper or tinned copper in accordance with VDE 0281 Part 5,HD21.5S3 IEC 227-5
Insulation:PVC/TI2 PVC in accordance with DIN VDE 0281.
Color ID:In accordance with HD 402 Standard
Jacket Material:PVC/TM2 PVC
Application Standard:  HD21.5, VDE 0281, CEI 20-20/5, CEI 20-35 (EN60332-1), CEI 20-52,CE Low voltage 73/23/EEC & 93/68/EEC

H05VV-F Features & Conformity:
Features : Super fine conductor, flexible for small bending angle . Durable for certain external mechanical forces
In accordance with EU coordination standard
Conformity Approval : RoHS   CE

H05VV-F Technical Parameter:
Rated Voltage:2000V In accordance with DIN VDE 0281 Part 2 HD21.2
Min. bending Radius
Fixed Installation:  5×D(Cable OD)
Movable Installation:  8×D(Cable OD)
Temperature Range
Fixed Installation:  -20 to +70°C
Movable Installation:  -5 to +70°C
