UL1185 Shielded 3 Conductor Guitar Circuit Wire Hookup Wire
B&T (Zhangzhou) Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：for General Purpose Internal Wiring of Appliance
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：UL1185
- Material Shape：Flat Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, UL, CCC, RoHS, Reach
- Brand：B&T
- According to：UL Subject758, UL1581, C22.2
- Test：Passes UL VW-1 & CSA FT1 Vertical Flame Test
- Conductor：Stranded, Tinned or Bare Copper Conductor
- Packing：100m,Roll, 305m,Roll, Wrap Plastic Film Packaging
- Company Type：Manufacturer
- Factory Directly：Big Discount with Large Order
- Service：OEM, ODM
- Sample：Conventional Sample Free
- Producing Experience：10 Years
- No. of Cores：One Core or Multi-Cores
- Transport Package：610feet in Roll
- Specification：2pin 22 AWG 2 Conductors
- Trademark：B&T
- Origin：Xiamen, Fujian
- HS Code：8544492100
- Production Capacity：300, 000km
Description
NO.of Cond/mmInsulated Thick. Braid Shield Jacket Thick. Outside Thick. mm No./d mm mm 30 7/0.1 0.41 32/0.10 0.40 2.10 28 7/0.127 0.41 34/0.10 0.40 2.20 26 7/0.16 0.41 37/0.10 0.40 2.30 24 11/0.16 0.41 40/0.10 0.40 2.40 22 17/0.16 0.41 45/0.10 0.40 2.60 20 21/0.178 0.41 50/0.10 0.40 2.80 18 34/0.178 0.41 58/0.10 0.40 3.10 16 26/0.254 0.41 66/0.10 0.40 3.40 28 1/0.320 0.41 33/0.10 0.40 2.15 26 1/0.404 0.41 36/0.10 0.40 2.25 24 1/0.511 0.41 38/0.10 0.40 2.35 22 1/0.643 0.41 42/0.10 0.40 2.50 20 1/0.813 0.41 46/0.10 0.40 2.65 18 1/1.024 0.41 51/0.10 0.40 2.85
