Hmwpe Sheath PVDF Insulation Cathodic Protection Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：Kynar Hmwpe
- Insulation Material：PVDF
Base Info
- Model NO.：Cathodic Protection Power Cable
- Material Shape：Round Wire
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Executive standard
- ASTM specifications D-1248
Application
A direct earth burial, DC lead, cathodic protection cable for use in deep anode groundbed installations, designed to withstand corrosive gases.
Construction
Maximum Overall Dia
(mm)
Thickness of Insulation
(mm)
Dia over
Core
(mm)
Thickness of
Sheath
(mm)
Nominal
Overall Dia
(mm)
Weight
(Kg/km)
1x6
3.12
0.7
4.5
1.4
7.3
104
1x10
4.05
0.7
5.5
1.4
8.3
150
1x16
5.10
0.7
6.5
1.4
9.3
214
1x25
6.40
0.9
8.2
1.4
11.0
317
1x35
7.50
0.9
9.3
1.4
12.1
420
1x50
8.90
1.0
11.1
1.4
14.2
560
1x70
10.70
1.1
13.2
1.5
16.4
787
1x95
12.60
1.1
15.0
1.5
18.3
1050
1x120
14.98
1.2
17.6
1.6
21.2
1450
1x150
15.96
1.4
19.0
1.7
22.8
1650
1x185
17.78
1.6
21.3
1.7
25.1
2030
1x240
20.52
1.7
24.3
1.9
28.4
2660
