PVC Elevator Cable 318-Y / H05VV-F/H03VV-F BS En 50525-2-11 Flexible Copper Wire PVC Insulated PVC Sheathed Wire Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：bv
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：318-Y H05VV-F
- Brand：Feiya
- Rate Voltage：300,500V
- OEM&ODM：Yes
- Intended for Use：Outdoor Use or Industrial Applications
- Other Name：Manguera Cable
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：solid, stranded, Flexible
- Trademark：Feiya
- Origin：China
- HS Code：8544
- Production Capacity：80000 Meter,Meters Per Month
Description
Application scope:
For internal wiring in switchboard of electrical appliance&wiring board of power distribution unit, connecting switch cubicle ofelectronics and electrical equipment, as well as wiring in installationsof power supplying and lighting systems with exposed and embedded conduit.
Structure:
Conductor: Bare copper or tinned copper according to IEC 60228, Standards VDE 0295 Class 5
Insulation: PVC/TI1 in accordance with DIN VDE 0281,Part 1. HD21.1
Color ID: in accordance with HD 402 Standard
Application Standard: HD 21.3 S3, VDE-0281 Part-3, CE Low Voltage Diretive, 73/23/EEC and 93/68/EEC
Features & Conformity:
Features & Conformity: Solid or stranded multi core cable, easypeeling,easy-cutting, convenient for installation. In accordance with EU Harmonized Standards.
Conformity Approval: CE
Technical Parameters:
Rated Voltage: 300/500V
Test Voltage: in accordance with DIN VDE 0281 Part 2 HD21.2
Min. bending Radius:
Fixed Installation: 12.5×D(Cable OD)
Movable Installation: 12.5×D(Cable OD)
Temperature Range:
Fixed Installation: -20 To +70ºC
Movable Installation: -5 To +70ºC
