• Model NO.：SHPT
• Material Shape：Flat Wire
• Range of Application：Water Pipe
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE, IP68
• Brand：Senphus
• Voltage：230V,120V,
• Heating Cable Lengths：1~61m
• Power：16W,M, 7W,FT
• with Thermostat：Imported From Japan
• Certificate：Ce, GS, VDE,IP68
• Cold Cable Length：2m or You Need
• Transport Package：Carton
• Specification：CE, UL
• Trademark：senphus
• Origin：China
• HS Code：85168000
• Production Capacity：6000PCS ,Month

               Senphus type
Heated section Length
Power
With thermostat
Without thermostat
M
W
SHPT-16-2M-2
SHPT-16-2M
2
32
SHPT-16-4M-2
SHPT-16-4M
4
64
SHPT-16-6M-2
SHPT-16-6M
6
96
SHPT-16-8M-2
SHPT-16-8M
8
128
SHPT-16-10M-2
SHPT-16-10M
10
160
SHPT-16-12M-2
SHPT-16-12M
12
192
SHPT-16-13M-2
SHPT-16-13M
13
208
SHPT-16-14M-2
SHPT-16-14M
14
224
SHPT-16-16M-2
SHPT-16-16M
16
256
SHPT-16-19M-2
SHPT-16-19M
19
304
SHPT-16-22M-2
SHPT-16-22M
22
352
SHPT-16-25M-2
SHPT-16-25M
25
400
SHPT-16-36M-2
SHPT-16-36M
36
576
SHPT-16-37M-2
SHPT-16-37M
37
592
SHPT-16-48M-2
SHPT-16-48M
48
768
SHPT-16-49M-2
SHPT-16-49M
49
784
Note
Voltage, Power, Cold Lead Plug, ect, can be designed according to customer's requirements. For example, 220/230V, 17w/m,16w/m or 20w/m,23w/m,etc.

Thermostat: imported from Japan

Package: plastic bag+small carton + big carton(16 or 10 small in one big carton)

The advantage of  water pipe heating cable:

 Easy

Fit heating cable with insulating tape to the water pipe. Then only plug in the mains cord-READY

Safe

CE-approved

Comfortable

Never thaw out water pipes again or carry heavy water buckets in winter. Suitable for all

water pipes whatever plastic or copper

Trusty

The thermostat automatically switches the heating cable as soon as the water pipe drops below +3

degree. Additionally an insulating tube can be used for maximum protection down to -45 degree.

Attention!

Do not cut the heating cable!

Do not install where it can be damaged by game animals.-protect against biting.

Basically do not use tie wrap by installation

Frost-proof water pipes with this heating cable:

calibre
15mm
22mm
28mm
35mm
42mm
48mm
60mm
76mm
Without pipe insulation
-20°C.
-13°C.
-10°C.
-7°C.
-5°C.
-4°C.
-3°C.
-2°C.
With 13mm pipe insulation
-45°C.
-45°C.
-40°C.
-40°C.
-35°C.
-30°C.
-25°C.
-20°C.



Installation:
first unwind the heating cable. The cable must never be connected to the power line when it is wound up.
if the cable is too inflexible because of low temperatures, unwind it and put it for some minutes into the plug.
afterwards you can pass the cable.
the area around the pipe where you want to connect it with the cable must be accessibly and non-attached.
the heating cable can not be passed behind walls
put the thermostat with the round black contact area tightly on the coolest point of the pipe and fix it with insulating tape.
finally put the whole cable on the pipe and fasten it every 30~60cm with insulating tape.
attention: the cable must be fastening straight on the pipe
now you can check if your cable
works.
afterwards insulate the water pipe and the heating cable with mineral rock wool or foam. Attention: never use more than 13mm of this material to insulate.
in general the heating cable must be protected against mechanical damage or biting.
the heating cable can not be put into liquids.
finally plug the cable into a 230V main plug
