- Model NO.:AAAC
- Wire Core Material:Aluminum Alloy
- Certification:ISO, CCC, CE, RoHS, UL, VDE
- Model:Zs-AAAC16-6-222
- Brand:Dayuan
- Supplier′s Nature:Manufacturer
- Conductor:Annealed Wire, Solid or Stranded
- Certificate:ISO, TUV, CCC, IEC
- Specification Type:ASTM B399
- OEM:Ok
- ODM:Ok
- Transport Package:Wooden Drum, as Request
- Specification:IEC, ISO, GB, TUV, CCC
- Trademark:Da Yuan
- Origin:Henan, China
- HS Code:7614100000
- Production Capacity:8000 Kilometers,Month
Code Name | Corss Sectional Area (MCM/AWG) | Corss Sectional Area (mm2) | Number of Wire | Diameter of Wires | Rated Strength (KN) | Appro.Weight | Max.D.C.resistance Of Conductor At 20ºC(Ω/km) |
In./mm | (lb/1000ft) | (Kg/km) |
Akron | 30.58/6 | 15.5 | 7 | 0.0661/1.68 | 4.92 | 28.52 | 42.58 | 2.159 |
Alton | 48.59/4 | 24.7 | 7 | 0.0834/2.12 | 7.83 | 45.40 | 67.80 | 1.356 |
Ames | 77.47/2 | 39.2 | 7 | 0.1052/2.67 | 12.4 | 72.24 | 107.5 | 0.8547 |
Azusa | 123.3/0 | 62.4 | 7 | 0.1327/3.37 | 18.9 | 114.9 | 171.3 | 0.5365 |
Anaheim | 155.4/00 | 78.6 | 7 | 0.1490/3.78 | 23.8 | 144.9 | 215.6 | 0.4264 |
Amherst | 195.7/000 | 99.3 | 7 | 0.1672/4.25 | 30.0 | 182.5 | 272.5 | 0.3373 |
Alliance | 246.9/0000 | 125 | 7 | 0.1878/4.77 | 37.8 | 230.2 | 343.2 | 0.2678 |
Butte | 312.8 | 159 | 19 | 0.1283/3.26 | 46.5 | 291.6 | 435.1 | 0.2112 |
Canton | 394.5 | 200 | 19 | 0.1441/3.66 | 58.6 | 367.9 | 548.5 | 0.1676 |
Cairo | 465.4 | 236 | 19 | 0.1565/3.98 | 69.2 | 433.9 | 648.6 | 0.1417 |
Darien | 559.4 | 284 | 19 | 0.1716/4.36 | 83.1 | 521.7 | 778.3 | 0.1181 |
Elgin | 652.4 | 331 | 19 | 0.1853/4.71 | 97.0 | 608.3 | 908.3 | 0.1012 |
Flint | 740.8 | 375 | 37 | 0.1415/3.59 | 107 | 690.8 | 1028 | 0.08944 |
Greeley | 927.2 | 470 | 37 | 0.1583/4.02 | 135 | 864.6 | 1289 | 0.07133 |
All Aluminum Alloy Conductor-AAAC(ASTM B399 Standard Sizes) Conductor Size (cmil) | Corss Sectional Area (mm2) | Number of Wire | Diameter of Wires | Rated Strength (KN) | Appro.Weight | Max.D.C.resistance Of Conductor At 20ºC (Ω/km) |
In./mm | (lb/1000ft) | (Kg/km) |
66360 | 33.5 | 7 | 0.0974/2.47 | 10.6 | 1632 | 2431 | 0.99870 |
105600 | 53.5 | 7 | 0.1228/3.12 | 17.0 | 1399 | 2082 | 0.62592 |
133100 | 67.3 | 7 | 0.1379/3.50 | 20.4 | 1165 | 1732 | 0.49738 |
167800 | 84.9 | 7 | 0.1548/3.93 | 25.7 | 932.5 | 1393 | 0.39450 |
211600 | 107 | 7 | 0.1739/4.42 | 32.5 | 839.7 | 1250 | 0.31188 |
400000 | 203 | 19 | 0.1451/3.69 | 59.5 | 745.6 | 1109 | 0.16486 |
450000 | 228 | 19 | 0.1539/3.91 | 66.8 | 699.6 | 1045 | 0.14683 |
500000 | 253 | 19 | 0.1622/4.12 | 74.2 | 652.3 | 971.2 | 0.13224 |
550000 | 279 | 37 | 0.1219/3.10 | 83.9 | 605.7 | 905.5 | 0.11995 |
600000 | 303 | 37 | 0.1273/3.23 | 91.0 | 559.1 | 831.9 | 0.11049 |
650000 | 330 | 37 | 0.1325/3.37 | 94.9 | 605.7 | 905.5 | 0.10150 |
700000 | 354 | 37 | 0.1375/3.49 | 101 | 652.3 | 971.2 | 0.09464 |
750000 | 381 | 37 | 0.1424/3.62 | 109 | 699.6 | 1045 | 0.08796 |
800000 | 404 | 37 | 0.1470/3.73 | 116 | 745.6 | 1109 | 0.08285 |
900000 | 456 | 37 | 0.1560/3.96 | 131 | 839.7 | 1250 | 0.07351 |
1000000 | 508 | 37 | 0.1644/4.18 | 146 | 932.5 | 1393 | 0.06597 |
1250000 | 631 | 61 | 0.1431/3.63 | 179 | 1165 | 1732 | 0.05306 |
1500000 | 759 | 61 | 0.1568/3.98 | 215 | 1399 | 2082 | 0.04414 |
1750000 | 886 | 61 | 0.1694/4.30 | 251 | 1632 | 2431 | 0.03781 |
All Aluminum Alloy Conductor-AAAC(ASTM B399 Standard Sizes)Conductor Size (mm2) | Number of Wire | Diameter of Wires(mm) | Rated Strength (KN) | Appro.Weight (Kg/km) | Max.D.C.resistance Of Conductor At 20ºC (Ω/km) |
40 | 7 | 2.70 | 12.7 | 110.0 | 0.83580 |
50 | 7 | 3.02 | 15.9 | 137.6 | 0.66806 |
63 | 7 | 3.39 | 19.1 | 173.4 | 0.53019 |
80 | 7 | 3.81 | 24.1 | 219.0 | 0.41974 |
100 | 7 | 4.26 | 30.2 | 273.8 | 0.33574 |
112 | 7 | 4.51 | 33.8 | 306.8 | 0.29955 |
125 | 19 | 2.89 | 38.3 | 342.0 | 0.26788 |
140 | 19 | 3.06 | 42.9 | 383.4 | 0.23973 |
160 | 19 | 3.27 | 46.7 | 437.8 | 0.20993 |
180 | 19 | 3.47 | 52.6 | 493.0 | 0.18643 |
200 | 19 | 3.66 | 58.6 | 548.5 | 0.167758 |
224 | 19 | 3.87 | 65.5 | 613.2 | 0.14988 |
250 | 19 | 4.09 | 73.1 | 684.9 | 0.13419 |
280 | 37 | 3.10 | 83.9 | 766.2 | 0.11995 |
315 | 37 | 3.29 | 90.2 | 863.0 | 0.10650 |
355 | 37 | 3.50 | 102 | 976.7 | 0.09410 |
400 | 37 | 3.71 | 115 | 1097 | 0.08375 |
450 | 37 | 3.94 | 129 | 1238 | 0.07426 |
500 | 37 | 4.15 | 143 | 1373 | 0.06693 |
560 | 37 | 4.39 | 161 | 1537 | 0.05981 |
630 | 37 | 4.66 | 181 | 1731 | 0.05308 |
Standard: BS EN50183Code name | Calculated area | No of wires | Diameter | Weight | Rated strength | Max D.C. resistance at 20ºC |
Wire | Cond |
| mm2 | | mm | mm | Kg/km | KN | Ω/km |
Box | 18.8 | 7 | 1.85 | 5.55 | 51.4 | 5.55 | 1.7480 |
Acacia | 23.8 | 7 | 2.08 | 6.24 | 64.9 | 7.02 | 1.3828 |
Almond | 30.1 | 7 | 2.34 | 7.02 | 82.2 | 8.88 | 1.0926 |
Cedar | 35.5 | 7 | 2.54 | 7.62 | 96.8 | 10.46 | 0.9273 |
Deodar | 42.2 | 7 | 2.77 | 8.31 | 115.2 | 12.44 | 0.7797 |
Fir | 47.8 | 7 | 2.95 | 8.85 | 130.6 | 14.11 | 0.6875 |
Hazel | 59.9 | 7 | 3.30 | 9.90 | 163.4 | 17.66 | 0.5494 |
Pine | 71.6 | 7 | 3.61 | 10.8 | 195.6 | 21.14 | 0.4591 |
Holly | 84.1 | 7 | 3.91 | 11.7 | 229.5 | 24.79 | 0.3913 |
Willow | 89.7 | 7 | 4.04 | 12.1 | 245.0 | 26.47 | 0.3665 |
Oak | 118.9 | 7 | 4.65 | 14.0 | 324.5 | 65.07 | 0.2767 |
Mulberry | 150.9 | 19 | 3.18 | 15.9 | 414.3 | 44.52 | 0.2192 |
Ash | 180.7 | 19 | 3.48 | 17.4 | 496.1 | 53.31 | 0.1830 |
Elm | 211.0 | 19 | 3.76 | 18.8 | 579.2 | 62.24 | 0.1568 |
Poplar | 239.4 | 37 | 2.87 | 20.1 | 659.4 | 70.61 | 0.1387 |
Sycamore | 303.2 | 37 | 3.23 | 22.6 | 835.2 | 89.40 | 0.1095 |
Upas | 362.1 | 37 | 3.53 | 24.7 | 997.5 | 106.82 | 0.0917 |
Yew | 479.0 | 37 | 4.06 | 28.4 | 1319.6 | 141.31 | 0.0693 |
Totara | 498.1 | 37 | 4.14 | 29.0 | 1372.1 | 145.93 | 0.0666 |
Rubus | 586.9 | 61 | 3.50 | 31.5 | 1622.0 | 173.13 | 0.0567 |
Sorbus | 659.4 | 61 | 3.71 | 33.4 | 1822.5 | 194.53 | 0.0505 |
Araucaria | 821.1 | 61 | 4.14 | 37.3 | 2269.4 | 242.24 | 0.0406 |
Redwood | 996.2 | 61 | 4.56 | 41.0 | 2753.2 | 293.88 | 0.0334 |
Relation Products
3. Our Services:
Luoyang Da Yuan Cable Factory Co., Ltd., a professional wires and cables manufacturer for 6 years in China. Da Yuan attends International Exhibitions every year, we support to offer many kinds of wires and cables, such as xlpe/pvc electrical power cable, control power cable, aerial cable, ABC, AAC, AAAC, ASCR cables, and XLPO/PVC Solar PV Cable etc. We can produce the standard: ASTM, BS, CSA, IEC, ASMC, DIN as your need.
1). Factory: 200,081 square meters, available for OEM&ODM;
2). Lead time: 5-7 working days after payment received;
3). Authentication: CCC,ISO9001, CQC, etc;
4). Payment terms: T/T, L/C;
5). Guarantee: 17 years;
6). QC inspection: Strict inspection before delivery;
4.After-sales Service:
1). All our cables will be tested well in production and before delivery.
2). Please contact us if any problem, we will respond within 24 hours.
5. Company Certifications:
National Products Safety Cerficcation;
ISO9001 Quality System Certification;
CCC Chinese National Compulsory Products Certification;
Occupational Health Safety Management System Certification;
Environmental Management System Certification;
Production License of Industrial Products;
International Standard Products Sysmbol Certificate, etc.
