CAT6A U/FTP Copper Low Smoke LSZH 600MHz Network Cable
Hangzhou Risun Cable Co., Ltd.- Application:Local Communication Cable, LAN Cable
- Conductor Material:Copper
- Cover Material:PVC
- Type:Cat 6
- Material Shape:Round Wire
- Conductor Type:Stranded
Base Info
- Model NO.:CAT6A U,FTP
- Wire Core Material:Bare Copper Wire
- Certification:CE, ISO, RoHS, ETL
- Model:CAT6
- Brand:Risun
- Color:Lilac
- Inner Conductor:23AWG Bc,CCA
- Nom. Thick:0.6mm
- Export Length:100m,Roll, 200m,Roll, 305m,Roll
- Pairs:4 Pairs
- Transport Package:Pull out Box, Carton Box, Pallet
- Specification:0.56cu, 1.04HDPE, 7.3PVC, LSZH
- Trademark:Risun
- Origin:Zhejiang, China
- HS Code:8544491100
- Production Capacity:30000boxes,Month
Description
U/FTP CAT6 Lan CableConductor 23AWG (0.57mm)Bare Copper Insulation 1.04mm HDPE Insulation material Foam skin Polyethylene Number of pairs 4 Pair screen Pair screen Sheath halogen free LSHF-FR Color Lilac or as required Certification ETL/CE/ROHS/ISO9001/CPR Packing 305m/Drum or 500m/Drum Cat6a oxygen free copper twisted pair data cable with low smoke zero halogen sheath and individual pair aluminium foil screen.
Supplied on a wooden drum reel and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications.
Low smoke zero halogen sheath material compliant to RoHS minimises the risk of thick black smoke and poisonous fumes in the event of a fire
AWG 23 oxygen free solid copper conductor
Supplied on a sturdy wooden drum reel
Passes Cat6a fluke test 100m at 600MHz
Complies to TIA/EIA-568 Cat6a standard
HDBaseT Compliant
Conductor Solid OFC
Strands 8 x 1/0.57mm
Cable : diameter 7.5mm
Screen Aluminium foil
Insulation PE 0.385mm thickness
Sheath LSZH 0.55mm thickness
Capacitance 6.6nF/100m
DC resistance @ 20C <7.8 Ohms/100m
Impedance (1 to 250MHz) 100+/-15 Ohms
Impedance (250 to 500MHz) 100+/-22 Ohms
Return loss > 25dB @100m
Attenuation <45.3dB @100m
NEXT > 74.3dB
PSNEXT > 72.3dB
ELFEXT > 14dB
PSELFEXT > 11dB
Phase delay <570ns
Cable colour Lilac
Length 305m
Company Introduction
FAQ
Q1. ARE YOU TRADING COMPANY OR MANUFACTURER? A: We are factory.
Q4. DO YOU PROVIDE SAMPLES? IS IT FREE OR EXTRA?A: Yes,we welcome sample order to test and check quality.we could offer the sample for free charge but do not pay freight.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6.IS IT OK TO PRINT MY LOGO ON CABLES ?
Supplied on a wooden drum reel and marked at 1 metre intervals. This cable is designed for high speed data transmission such as Gigabit Ethernet applications.
Low smoke zero halogen sheath material compliant to RoHS minimises the risk of thick black smoke and poisonous fumes in the event of a fire
AWG 23 oxygen free solid copper conductor
Supplied on a sturdy wooden drum reel
Passes Cat6a fluke test 100m at 600MHz
Complies to TIA/EIA-568 Cat6a standard
HDBaseT Compliant
Conductor Solid OFC
Strands 8 x 1/0.57mm
Cable : diameter 7.5mm
Screen Aluminium foil
Insulation PE 0.385mm thickness
Sheath LSZH 0.55mm thickness
Capacitance 6.6nF/100m
DC resistance @ 20C <7.8 Ohms/100m
Impedance (1 to 250MHz) 100+/-15 Ohms
Impedance (250 to 500MHz) 100+/-22 Ohms
Return loss > 25dB @100m
Attenuation <45.3dB @100m
NEXT > 74.3dB
PSNEXT > 72.3dB
ELFEXT > 14dB
PSELFEXT > 11dB
Phase delay <570ns
Cable colour Lilac
Length 305m
Company Introduction
FAQ
Q1. ARE YOU TRADING COMPANY OR MANUFACTURER? A: We are factory.
Q2. HOW LONG IS YOUR DELIVERY TIME?
A:Generally it is 5-10 days, or it is 20-30 days if the goods are not in stock,its is according to quantity.Q3. DO YOU HAVE ANY MOQ LIMIT FOR ORDER?
A: Normally, 10kms per one specification and one colorQ4. DO YOU PROVIDE SAMPLES? IS IT FREE OR EXTRA?A: Yes,we welcome sample order to test and check quality.we could offer the sample for free charge but do not pay freight.
Q5. HOW TO PROCEED AN ORDER FOR CABLES?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
