Tccs Wire (Tinned Copper Clad Steel) Conductivity 21%
NINGBO BEVIEW TRADING CO., LTD.- Application：Coaxial Cable, LAN Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Transport Package：Export Carton
Base Info
- Model NO.：TCCS 0.10mm-1.2mm(conductivity 21%)
- Production Capacity：300, 000kg,Month
Description
| TCCS Conductivity 21% (Parameter table) |
|
Wire gauge |
Nominal diameter |
Diameter difference |
Resistivity |
Measured resistance |
Density | Conductivity | Annealed |
half of hard state |
Hard | |||
| (20 ºC ) | (20 ºC ) | (20 ºC ) | (20 ºC ) | Elongation |
Tensile Strength |
Elongation |
Tensile Strength |
Elongation |
Tensile Strength |
|||
| 26 | 0.405 | 0.005 | 83.1 | 646 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 25 | 0.455 | 0.005 | 83.1 | 512 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 24 | 0.511 | 0.005 | 83.1 | 406 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 23 | 0.573 | 0.005 | 83.1 | 452 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 22 | 0.643 | 0.006 | 83.1 | 256 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 21 | 0.723 | 0.007 | 83.1 | 202 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 20 | 0.812 | 0.008 | 83.1 | 160.9 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 19 | 0.912 | 0.009 | 83.1 | 127.5 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 18 | 1.024 | 0.01 | 83.1 | 101 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 17 | 1.15 | 0.011 | 83.1 | 80.2 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 16 | 1.291 | 0.012 | 83.1 | 63.6 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 15 | 1.45 | 0.014 | 83.1 | 50.4 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 14 | 1.628 | 0.016 | 83.1 | 40 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 13 | 1.828 | 0.018 | 83.1 | 31.7 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 12 | 2.053 | 0.02 | 83.1 | 25.1 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 11 | 2.305 | 0.023 | 83.1 | 20 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
| 10 | 2.588 | 0.025 | 83.1 | 15.8 | 7.95 | 21 | 12 | 320 | 1.5 | 430 | 1 | 758 |
