• Model NO.：ZX-A
• Production Capacity：2000 PCS, Year

Basic Info.

Model NO. ZX-A Production Capacity 2000 PCS/ Year

Product Description

ZX-A cable identification instrument is used to identify a particular cable during power cable laying, transfer, maintenance, and fault location, featured with accurate, fast, simple operation and wide application, light weight and compact structure, lithium battery power. This type of live cable identification instrument consists of a cable identification transmitter, a cable identification receiver, a transmitting caliper, a receiving caliper and an output signal connecting line. It has high power current pulse output; clear receiving signal, high sensitivity, ability of effectively suppressing the field power frequency interference; accurate and rapid cross-section area power cables; built in isolation transformer to ensure personal safety, no need to disconnect the connection between the two ends of the cable and the power distribution equipment.

Features

Applicable to identification of both non working cable and live cablesLithium battery-powered, 3 to 5 hours continuous workAdvance technology with reliable performance, applied to extra long cables, various HV/LV power cables

1.Transmitter
1) Maximum pulse peak output current: 30A
2) Pulse repetition frequency: 1 time / 2 seconds
3) Power supply voltage: AC220V (± 10%), charging voltage: DC12V
4) Weight: 8kg
2.Receiver
1) Receiver sensitivity: 40dB
2) Power: two AA batteries
3) Weight: 0.2kg
