- Model NO.:minicable
- Conductor Insulation:Fluoropolymer
- Outer Insulation:PVC
- Cold Lead:2-Wire Plus Ground Braid 2.5 Length
- Color:Customized
- Transport Package:Innner Carton Master Carton
- Specification:CE EAC TUV ROHS
- Trademark:jiahong
- Origin:Anhui Wuhu
Cable Construction: | Twin conductor |
Rated Voltage: | 230V |
Output: | 12W/m & 18W/m |
Heating Element Size: | 12.5-150.0m (12W/m) & 7.5-154.2m (18W/m) |
Bending radius: | 25 mm |
Cable Diameter: | 3.6mm |
Conductor Insulation: | Fluoropolymer |
Outer Insulation: | PVC |
Max. Ambient Temp.: | 85ºF(30ºC) |
Min. Installation Temp.: | 40ºF(5ºC) |
Cold lead | 2.5m length |
Ordering Information230V | Length (m) | Watts (12W/m) | Amps | ohms |
Catalog Number |
MiniCable/12-150 | 12.5 | 150 | 0.7 | 352.7 |
MiniCable/12-225 | 18.8 | 225 | 1.0 | 235.1 |
MiniCable/12-300 | 25.0 | 300 | 1.3 | 176.3 |
MiniCable/12-375 | 31.3 | 375 | 1.6 | 141.1 |
MiniCable/12-450 | 37.5 | 450 | 2.0 | 117.6 |
MiniCable/12-525 | 43.8 | 525 | 2.3 | 100.8 |
MiniCable/12-600 | 50.0 | 600 | 2.6 | 88.2 |
MiniCable/12-675 | 56.3 | 675 | 2.9 | 78.4 |
MiniCable/12-750 | 62.5 | 750 | 3.3 | 70.5 |
MiniCable/12-900 | 75.0 | 900 | 3.9 | 58.8 |
MiniCable/12-1050 | 87.5 | 1050 | 4.6 | 50.4 |
MiniCable/12-1200 | 100.0 | 1200 | 5.2 | 44.1 |
MiniCable/12-1350 | 112.5 | 1350 | 5.9 | 39.2 |
MiniCable/12-1500 | 125.0 | 1500 | 6.5 | 35.3 |
MiniCable/12-1800 | 150.0 | 1800 | 7.8 | 29.4 |
230V | Length (m) | Watts (18W/m) | Amps | ohms |
Catalog Number |
MiniCable/18-135 | 7.5 | 135 | 0.6 | 391.9 |
MiniCable/18-200 | 11.1 | 200 | 0.9 | 264.5 |
MiniCable/18-270 | 15.0 | 270 | 1.2 | 195.9 |
MiniCable/18-400 | 22.2 | 400 | 1.7 | 132.3 |
MiniCable/18-535 | 29.7 | 535 | 2.3 | 98.9 |
MiniCable/18-600 | 33.3 | 600 | 2.6 | 88.2 |
MiniCable/18-680 | 37.8 | 680 | 3.0 | 77.8 |
MiniCable/18-800 | 44.4 | 800 | 3.5 | 66.1 |
MiniCable/18-935 | 51.9 | 935 | 4.1 | 56.6 |
MiniCable/18-1100 | 61.1 | 1100 | 4.8 | 48.1 |
MiniCable/18-1220 | 67.8 | 1220 | 5.3 | 43.4 |
MiniCable/18-1340 | 74.4 | 1340 | 5.8 | 39.5 |
MiniCable/18-1500 | 83.3 | 1500 | 6.5 | 35.3 |
MiniCable/18-1625 | 90.3 | 1625 | 7.1 | 32.6 |
MiniCable/18-1900 | 105.6 | 1900 | 8.3 | 27.8 |
MiniCable/18-2135 | 118.6 | 2135 | 9.3 | 24.8 |
MiniCable/18-2295 | 127.5 | 2295 | 10.0 | 23.1 |
MiniCable/18-2775 | 154.2 | 2775 | 12.1 | 19.1 |
Why choose Jiahong ?
Jiahong is the largest heating cable manufacturer in Asia.
We replaced Raychem as heating jacket supplier of GE. Grainger sells heating cable only from Raychem and Jiahong . We take big part of heating cable share from Easyheat in home depot.
Jiahong can be your reliable supplier. In heating cable, we are the only one in
China whose products are widely sold in North American market, typically GE,
Homedepot and Grainger, directly competing with NA's top companies. We are
the only one in China that has UL, CSA, ETL, TUV, CE, ATEX etc., the only one
in China that import key materials from DuPont (USA), Daikin (Japan) and
Solvay (Europe), the only one in China that Passed ISO 9001 by BV company.
