Copper Conductor Material and XLPE Insulation Material 2X4mm2 Wire Cable
Henan Hongda Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Hous Building
- Conductor Material：Copper
- Sheath Material：XLPE
- Insulation Material：PVC
Base Info
- Model NO.：IEC 60227
- Material Shape：Round Wire
- Range of Application：Hous Building
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE, Copper Conductor Material and XLPE Insulation Mate
- Brand：Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：2 Core
- Cross Section：4mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：70°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：300,300V
- Design Standard：IEC 60502-1
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：Three Year
- Transport Package：by Sea
- Specification：Copper Conductor Material and XLPE Insulation Mate
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：50000 Meter,Month
Description
60227 IEC
53(RVV)
300/500V2×0.75 24/0.20 0.6 0.8 6.0 7.6 26.0 26.7 0.011 2×0.75 24/0.20 0.6 0.8 3.8×6.0 5.2×7.6 26.0 26.7 0.011 2×1 32/0.20 0.6 0.8 6.4 8.0 19.5 20.0 0.010 2×1.5 30/0.25 0.7 0.8 7.4 9.0 13.3 13.7 0.010 2×2.5 50/0.25 0.8 1.0 8.9 11.0 7.98 8.21 0.009 3×0.75 24/0.20 0.6 0.8 6.4 8.0 26.0 26.7 0.011 3×1 32/0.20 0.6 0.8 6.8 8.4 19.5 20.0 0.010 3×1.5 30/0.25 0.7 0.9 8.0 9.8 13.3 13.7 0.010 3×2.5 50/0.25 0.8 1.0 9.6 12.0 7.98 8.21 0.009 4×0.75 24/0.20 0.6 0.8 6.8 8.6 26.0 26.7 0.011 4×1 32/0.20 0.6 0.9 7.6 9.4 19.5 20.0 0.010 4×1.5 30/0.25 0.7 1.0 9.0 11.0 13.3 13.7 0.010 4×2.5 50/0.25 0.8 1.1 10.5 13.0 7.98 8.21 0.009 5×0.75 24/0.20 0.6 0.9 7.4 9.6 26.0 26.7 0.011 5×1 32/0.20 0.6 0.9 8.3 10.0 19.5 20.0 0.010 5×1.5 30/0.25 0.7 1.1 10.0 12.0 13.3 13.7 0.010 5×2.5 50/0.25 0.8 1.2 11.5 14.0 7.98 8.21 0.009
53(RVV)
300/500V
