• Model NO.：RG11
• Material Shape：Round Wire
• Range of Application：RF Signal Transmission in Matv, CATV and CCTV
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Feiya
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：US $0.1-0.99, Meter
• Trademark：FengDa
• Origin：Tianjin, China
• HS Code：8544492100
• Production Capacity：5, 000, 000km,Year

Cable TypeSeries 11Center Conductor TypeSolidConstruction TypeNon-armoredJacket ColorWhiteSupported ApplicationVideo
DimensionsCable Length304.8 m | 1000 ftDiameter Over Center Conductor, specific0.0641 in per 1 strandDiameter Over Dielectric7.061 mm | 0.278 inDiameter Over Inner Shield (Braid)7.595 mm | 0.299 inDiameter Over Inner Shield (Tape)7.214 mm | 0.284 inDiameter Over Jacket Tolerance±0.008 inDiameter Over Jacket, nominal9.042 mm | 0.356 inDiameter Over Outer Shield (Braid)8.204 mm | 0.323 inJacket Thickness0.432 mm | 0.017 inJacket Thickness, minimum spot0.305 mm | 0.012 inCenter Conductor Gauge14 AWGInner Shield (Braid) Gauge36 AWGOuter Shield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance11 ohms/kft | 36.089 ohms/kmDielectric Strength, conductor to shield4000 VdcJacket Spark Test Voltage2500 VacNominal Velocity of Propagation (NVP)86 %Shield dc Resistance1.7 ohms/kft | 5.577 ohms/kmStructural Return Loss15 dB @ 1000-3000 MHz | 20 dB @ 5-1000 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialBare copperDielectric MaterialFoam FEPJacket MaterialPVCInner Shield (Braid) Coverage60 %Inner Shield (Braid) MaterialAluminumInner Shield (Tape) MaterialAluminum/PolyOuter Shield (Braid) Coverage40 %Outer Shield (Braid) MaterialAluminumOuter Shield (Tape) MaterialAluminum/Poly, non-bonded
