K TYPE 0.3/0.5/0.8mm Silicone Rubber Insulated Thermocouple Wire
Shanghai Tankii Alloy Material Co., Ltd.- Type：Insulated
- Conductor Type：Solid
- Application：Heating
- Conductor Material：Chromel Alumel
- Sheath Material：Rubber
- Insulation Material：Rubber
Base Info
- Model NO.：Type K
- Material Shape：Round Wire
- Range of Application：Temperature Measurement
- Certification：ISO9001, CE, RoHS
- Brand：Tankii
- Conductor：Chromel Alumel
- Dia：0.3,0.5,0.8,1.0,1.2,1.6,2.0,2.5,3.2mmm
- Grade：I,II,III
- Transport Package：100m,Coil 200m,Coil
- Specification：IEC,GB, 0.2mm, 0.5mm, 0.8mm, 1mm
- Trademark：TANKII
- Origin：Shanghai
- HS Code：9025900000
- Production Capacity：500000m,Year
Description
Conductor Name
Polarity
Code
Nominal Chemical Composition /%
Ni
Cr
Si
Ni-Cr
Positive
KP
90
10
--
Ni- Si
Negative
KN
97
--
3
Diameter/mm
Long time Working temperature /ºC
Short period Working temperature /ºC
0.3
700
800
0.5
800
900
0.8,1.0
900
1000
1.2,1.6
1000
1100
2.0,2.5
1100
1200
3.2
1200
1300
