• Model NO.：arvfv
• Wire Core Material：Aluminum
• Certification：ISO, CCC, SGS
• Model：Arvfv, Ar2V
• Brand：OEM
• Standard：NF C 32-322, IEC60502-1
• Rated Voltage：600,1000 Volts
• Armored：Steel Tape Armor
• Suitable for：Direct Burial Without Extra Mechanical Protection
• Flame Retardant：NF C 32-070 C2
• Transport Package：Drum or as Customer Require
• Specification：1.5mm2 to 400mm2
• Trademark：Hongda
• Origin：China
• HS Code：8544492100
• Production Capacity：10km,Day

Conductor:: rigid Aluminum wire, class  1 (Φ ≤ 4 mm²)
  stranded circular compacted Aluminum class 2 (Φ>4mm²)Insulation: XLPE crosslinked polyethylene (no dry cool)Outer sheath: PVCScreen: noDrain wire: noLead sheath: noConcentric cond.: noneInsulation integrity: noCircuit integrity: noArmouring: Steel Tape Armoured U-1000 Rvfv Arvfv Cable - Technical data and testsStandards: NF C 32-322Nominal voltage U0/U: 0,6/1 kVTest voltage (50 Hz): 4 kVMaximun voltage Um: 1,2 kVMaximun operating temperature: +90° CMaximun short circuit temperature: +250° CMin. operating temperature
(without mechanical shocks): -25° CMinimum installation and use temp.: -10° CMinimum bending radius per
D cable diameter (in mm): 6 x DCore colourssingle core : black
two cores : blue-brown
three  cores : brown-black-blue  (1,5/2,5 mmq); brown-black-gray (4 mmq)  or Y/G-blue-brown)
four cores : blue-brown-black-gray (or Y/G instead blue)
five cores : blue-brown-black-gray-Y/G (or black instead Y/G)Sheath colour: black

U-1000 ARVFV
Low Voltage Power Cable (0.6/1 kV)
XLPE insulated, aluminum conductor, Steel tape armor, PVC outer sheath cable

Application and Description

With a sheath and armor, U-1000 ARVFV is an enhanced version of the cables and U-1000 AR2V. They can be used in all industrial installations requiring mechanical protection.
These cables can be provided in hard and SH C1 (NF C 32-323) and HR (resistant to aliphatic hydrocarbons). The design and characteristics of the materials comply with IEC 60502-1.

Cable Parameter

AWG	Cross Section	Insulation thickness	Amour thickness	Minimum Sheath thickness	Maximum Overall diameter	Approx Cable weight
	mm^2	mm	mm	mm	mm	kg/km
8	U1000 ARVFV 2x10	0.7	0.2	1.4	18.5	420
6	U1000 ARVFV 2x16	0.7	0.2	1.5	20.5	540
4	U1000 ARVFV 2x25	0.9	0.2	1.6	24.5	760
2	U1000 ARVFV 2x35	0.9	0.2	1.7	27	930
8	U1000 ARVFV 3x10	0.7	0.2	1.5	19	470
6	U1000 ARVFV 3x16	0.7	0.2	1.5	22	590
4	U1000 ARVFV 3x25	0.9	0.2	1.6	26	830
2	U1000 ARVFV 3x35	0.9	0.2	1.7	29	1030
1	U1000 ARVFV 3x50	0.9	0.2	1.8	32.5	1290
2/0	U1000 ARVFV 3x70	1.1	0.2	2	37.5	1710
3/0	U1000 ARVFV 3x95	1.1	0.5	2.1	43.5	2610
4/0	U1000 ARVFV 3x120	1.2	0.5	2.3	47.5	3110
300MCM	U1000 ARVFV 3x150	1.4	0.5	2.4	53	3770
500MCM	U1000 ARVFV 3x185	1.6	0.5	2.5	58	4540
750MCM	U1000 ARVFV 3x240	1.7	0.5	2.7	65.5	5620
-	U1000 ARVFV 3x300	1.8	0.5	2.9	72	6830
1	U1000 ARVFV 3x50+35	1.0/09	0.2	1.9	34.5	1500
2/0	U1000 ARVFV 3x70+50	1.1/0.9	0.2	2	40	2000
3/0	U1000 ARVFV 3x95+50	1.1/1.0	0.5	2.2	45	2870
4/0	U1000 ARVFV 3x120+70	1.2/1.1	0.5	2.3	50	3460
300MCM	U1000 ARVFV 3x150+70	1.4/1.1	0.5	2.5	54	4090
500MCM	U1000 ARVFV 3x185+70	1.6/1.1	0.5	2.6	59	4980
750MCM	U1000 ARVFV 3x240+95	1.7/1.1	0.5	2.8	66	6210
8	U1000 ARVFV 4x10	0.7	0.2	1.5	20.5	540
6	U1000 ARVFV 4x16	0.7	0.2	1.6	23.5	700
4	U1000 ARVFV 4x25	0.9	0.2	1.7	28	1000
2	U1000 ARVFV 4x35	0.9	0.2	1.8	31.5	1230
1	U1000 ARVFV 4x50	1	0.2	1.9	35.5	1550
2/0	U1000 ARVFV 4x70	1.1	0.5	2.1	42.5	2490
3/0	U1000 ARVFV 4x95	1.1	0.5	2.3	47.5	3120
4/0	U1000 ARVFV 4x120	1.2	0.5	2.4	53	3780
300MCM	U1000 ARVFV 4x150	1.4	0.5	2.6	58.5	4550
500MCM	U1000 ARVFV 4x185	1.6	0.5	2.7	64.5	5490
750MCM	U1000 ARVFV 4x240	1.7	0.5	2.9	72.5	6860
-	U1000 ARVFV 4x300	1.8	0.5	3.1	79.5	8250
8	U1000 ARVFV 5x10	0.7	0.2	1.6	22.5	640
6	U1000 ARVFV 5x16	0.7	0.2	1.8	26	820
4	U1000 ARVFV 5x25	0.9	0.2	1.8	31	1190

Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas

FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 10-20 days if the goods are not in stock,
it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: 30% T/T in advance,70% T/T balance before shipment

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Any needs or question, please contact Vivian Mobile , we will be more pleasure to service you.
We are looking forward to your inquiry and nice cooperation.
