• Model NO.：AIRDAC SNE cable B2-13
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE
• Model：Concentric Cable
• Brand：Yifang Cable
• Name：Concentric Cable
• Transport Package：Drum
• Specification：10, 16mm2 Airdac SNE cable
• Trademark：Yifang
• Origin：China
• HS Code：8544492100
• Production Capacity：500, 000 Meters Per Month

Basic Info.

Model NO. AIRDAC SNE cable B2-13 Wire Core Material Bare Copper Wire Certification ISO, CCC, CE Model Concentric Cable Brand Yifang Cable Name Concentric Cable Transport Package Drum Specification 10, 16mm2 Airdac SNE cable Trademark Yifang Origin China HS Code 8544492100 Production Capacity 500, 000 Meters Per Month

Product Description

AIRDAC
Used for house connections. This cable can only be used for single phase supply. Cable is made to be suspended in the air. Cable is available as a Combined Neutral and Earth (CNE) and Separate Neutral and Earth (SNE) with coms wire available in Separate Neutral and Earth (SNE).
Combined Neutral and Earth (CNE) Airdac 600/1000V
Separate Neutral and Earth (SNE) Airdac 600/1000V
Separate Neutral and Earth (SNE) Airdac 600/1000V

Cable Size	Neutral Size	Earth Size	Pilot Cores	Overall Diameter	Cable Mass	Current Rating	Phase Core Impedance
mm²	mm²	mm²	mm	mm	kg/m	amps	ohms/km
10	10	7.5	2 x 0.5	12.8	0.32	90	2.34
16	16	10	2 x 0.5	14.5	0.485	125	1.47

Combined Neutral and Earth (CNE) Airdac 600/1000V

Cable Size	Earth Size	Overall Diameter	Cable Mass	Current Rating	Phase Core Impedance
mm²	mm²	mm	kg/m	amps	ohms/km
4	4	8.7	0.121	47	5.88
10	10	11	0.249	86	2.34


AIRDAC SNE Cable


10mm², AIRDAC SNE Cable    Mechanical Properties  * Cable size: 10mm²  * Phase Conductor (No.xOD): 7x1.35mm  * Nominal Insulation Thickness: 1.0mm  * Neutral Conductor (No.xOD): 7x1.33mm  * Earth Conductor (No.xOD): 3x1.78mm  * Nominal Sheath Thickness: 1.6mm  * Approximate Cable OD: 12.8mm  * Approximate Cable Mass: 320 kg/km  Installation Data (SAG* mm)  Span 10m :45  Span 20m :180  Span 30m :400  Span 40m :710  Span 50m :1110  Based on  UTS** :3600  MWT*** :900



16mm², AIRDAC SNE Cable   Mechanical Properties  * Cable size: 16mm²  * Phase Conductor (No.xOD): 7x1.67mm  * Nominal Insulation Thickness: 1.0mm  * Neutral Conductor (No.xOD): 7x1.76mm  * Earth Conductor (No.xOD): 3x2.20mm  * Nominal Sheath Thickness: 1.6mm  * Approximate Cable OD: 14.5mm  * Approximate Cable Mass: 485 kg/km  Installation Data (SAG* mm)  Span 10m: 40  Span 20m: 170  Span 30m: 380  Span 40m: 670  Span 50m: 1050  Based on  UTS** :5760  MWT*** :1440
