Nyy 4 Cores RM/Sm Cu/PVC/PVC Service Cable for 11kv Distribution Network
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：NYY-O, NYY-J
- Material Shape：Round Wire
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
We can customize various types of cable in accordance with your requirements XLPE / PVC insulated power cable
Construction :
Conductor
RE: Class 1 solid copper conductor
RM: Class 2 stranded copper conductor
Insulation
PVC (Polyvinyl Chloride)
Filler
PVC (Polyvinyl Chloride)
Sheath
PVC (Polyvinyl Chloride)
Techical Data :
Standard:IEC 60502-1 / VDE 0276 /NT88-22
Fixed installed: -30ºC up to 70ºC
At short circuit of max.5s up to 160ºC
Nominal Voltage : 600/1000V
Min inner bending radius:
Single coe:15D
Multi core:12D
Behaviour in fire:
Flame retardant cable acc.to IEC60332-1
Application:
Power and control cable for fixed installation. Can be used indoors, outdoors, underground, in concrete and in water.
NYY-O (without Green/Yellow earth conductor) also available
Technical Parameters:
