Yifang Cable Low Voltage Power Cable 3X240+95mm2 Cable U1000 RO2V NFC Standard Cables Industriels

YIFANG ELECTRIC GROUP INC.
  • Application：Construction, Underground, Industrial, Power Station
  • Voltage：Low Voltage Power Cable
  • Current：DC & AC
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：Cable U1000 RO2V 3x240+95mm2
  • Wire Core Material：Bare Copper Wire
  • Certification：ISO, CCC, CE
  • Model：YJV
  • Brand：Yifangcable
  • Rated Voltage：600,1000V
  • Size：Cable U1000 RO2V 3X240+95mm2
  • Standard：IEC 60502-1 or NFC
  • Armour：Non Armour
  • Insulation：XLPE
  • Sheath：PVC
  • Transport Package：Wooden Steel Drum
  • Specification：2.0m drum
  • Trademark：Yifangcable
  • Origin：China
  • HS Code：8544492100
  • Production Capacity：600km,Month

Description

TECHNICAL DATA SHEETCâble U1000 RO2V 3x240mm²+95mm²ItemDescriptionUnitData1Standard IEC 60502-12Size 3x240+1x95mm23Rated VoltagekV0.6/14Phase core   Cores 3 Norminal Cross Sectional Areamm2240 Conductor Compact sector stranded copper Standing No.Of Wireno.sMin.34 Max.DC Resistance at 20ºCΩ/km0.0754 Insulation XLPE Norminal Thicknessmm1.75Earth core   Cores 1 Norminal Cross Sectional Areamm295 Conductor Compact sector stranded copper Standing No.Of Wireno.sMin.15 Max.DC Resistance at 20ºCΩ/km0.193 Insulation XLPE Norminal Thicknessmm1.16Filler(if any) PP7Wrapping tape Non-woven clothing tape8Outer Sheath PVC Norminal Thicknessmm2.69Overall diametermm52.210Approx.Weightkg/km8425
