75 Ohm Telecom CATV RF RG6 Rg59 Standard Shield Coaxial Cable

Hangzhou Hongfeng Cable Co., Ltd.
  • Application：Coaxial Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PVC
  • Type：Coaxial Cable
  • Certification：ISO
  • Model：Rg59

Base Info

  • Model NO.：rg59
  • Brand：Hf
  • Jacket：PVC
  • Jacket Color：Black,White,Color
  • Impedance：75 Ohm
  • Braid Shied Material：Bc, Tc, CCA, CCS, Al-Mg(60%-95%)
  • Inner Conductor：CCS, CCA, Cu
  • Inner Conductor Diameter：1.02mm
  • Certificate：ISO9001, Cl2,CATV,Cm UL
  • Dielectric：4.57mm
  • Insulation Material：Bonded,Non Bonded
  • Jacket Diameter：6.1mm
  • Transport Package：Drum
  • Trademark：HF
  • HS Code：85442000
  • Production Capacity：100, 000kms,Year

Description

RG6 Coaxial Cable Introduce and Parameter : 75 Ohm    SHIELD SHIELDTRI-SHIELDQUAD-SHIELDCONDUCTOR MATERIALBC/CCSBC/CCXBC/CCXNom.Dia 18AWG18AWG18AWGDIELECTRICMATERIALFoamed PEFoamed PE Foamed PE Nom.Dia 4.57mm 4.57mm4.57mm SHIELDMATERIALAL Foil+AL Braiding AL-Foil+Braiding of AL
+AL-Foil(AL-Foil+Braiding of AL)*2COVERAGE40%-90%40%-90%40%/60%METERIALPVC/PEPVC/PEPVC/PEJACKETNom.Thick.0.80mm0.80mm0.86mmNom.Dia 6.91mm6.91mm 6.91mm
