- Model NO.：minimatD
- Certificate：CE Eac TUV
- Application：Under Tile
- Transport Package：Innner Carton Master Carton
- Specification：CE EAC TUV
- Trademark：jiahong
- Origin：Anhui Wuhu
- Production Capacity：17000PCS Per Day
| Cable Construction: | Twin conductor |
| Rated Voltage: | 230V |
| Output(standard): | 100W/m2 &150W/m2 ±10% accept customize |
| Cable spacing(standard): | 112mm & 80mm & 80mm accept customize |
| Cable Diameter(standard): | 3.6mm-4.2mm(1/7"-1/6" ) accept customize |
| Conductor Insulation(standard): | Fluoropolymer accept customize |
| Outer Insulation(standard): | PVC accept customize |
| Max. Ambient Temp.: | 85ºF(30ºC) |
| Min. Installation Temp.: | 40ºF(5ºC) |
| Cold lead(standard): | 2.5m length accept customize |
Ordering Information| 230V | Heated Area | Mat Dimensions | Watts (100W/m2) | Amps | ohms |
| Catalog Number | m2 | sq.ft. | m*m | in.*ft. |
| MinimatD/100-100-1.0 | 1.0 | 10.8 | 0.5*2 | 20*6.5 | 100 | 0.4 | 529.0 |
| MinimatD/100-150-1.5 | 1.5 | 16.1 | 0.5*3 | 20*9.7 | 150 | 0.7 | 352.7 |
| MinimatD/100-200-2.0 | 2.0 | 21.5 | 0.5*4 | 20*12.9 | 200 | 0.9 | 264.5 |
| MinimatD/100-250-2.5 | 2.5 | 26.9 | 0.5*5 | 20*16.1 | 250 | 1.1 | 211.6 |
| MinimatD/100-300-3.0 | 3.0 | 32.3 | 0.5*6 | 20*19.4 | 300 | 1.3 | 176.3 |
| MinimatD/100-350-3.5 | 3.5 | 37.7 | 0.5*7 | 20*22.6 | 350 | 1.5 | 151.1 |
| MinimatD/100-400-4.0 | 4.0 | 43.1 | 0.5*8 | 20*25.8 | 400 | 1.7 | 132.3 |
| MinimatD/100-450-4.5 | 4.5 | 48.4 | 0.5*9 | 20*29.1 | 450 | 2.0 | 117.6 |
| MinimatD/100-500-5.0 | 5.0 | 53.8 | 0.5*10 | 20*32.3 | 500 | 2.2 | 105.8 |
| MinimatD/100-600-6.0 | 6.0 | 64.6 | 0.5*12 | 20*38.8 | 600 | 2.6 | 88.2 |
| MinimatD/100-700-7.0 | 7.0 | 75.3 | 0.5*14 | 20*45.2 | 700 | 3.0 | 75.6 |
| MinimatD/100-800-8.0 | 8.0 | 86.1 | 0.5*16 | 20*51.7 | 800 | 3.5 | 66.1 |
| MinimatD/100-900-9.0 | 9.0 | 96.9 | 0.5*18 | 20*58.1 | 900 | 3.9 | 58.8 |
| MinimatD/100-1000-10 | 10 | 107.6 | 0.5*20 | 20*64.6 | 1000 | 4.3 | 52.9 |
| MinimatD/100-1200-12 | 12 | 129.2 | 0.5*24 | 20*77.5 | 1200 | 5.2 | 44.1 |
| 230V | Heated Area | Mat Dimensions | Watts (150W/m2) | Amps | ohms |
| Catalog Number | m2 | sq.ft. | m*m | in.*ft. |
| MinimatD/150-150-1.0 | 1.0 | 10.8 | 0.5*2 | 20*6.5 | 150 | 0.7 | 352.7 |
| MinimatD/150-225-1.5 | 1.5 | 16.1 | 0.5*3 | 20*9.7 | 225 | 1.0 | 235.1 |
| MinimatD/150-300-2.0 | 2.0 | 21.5 | 0.5*4 | 20*12.9 | 300 | 1.3 | 176.3 |
| MinimatD/150-375-2.5 | 2.5 | 26.9 | 0.5*5 | 20*16.1 | 375 | 1.6 | 141.1 |
| MinimatD/150-450-3.0 | 3.0 | 32.3 | 0.5*6 | 20*19.4 | 450 | 2.0 | 117.6 |
| MinimatD/150-525-3.5 | 3.5 | 37.7 | 0.5*7 | 20*22.6 | 525 | 2.3 | 100.8 |
| MinimatD/150-600-4.0 | 4.0 | 43.1 | 0.5*8 | 20*25.8 | 600 | 2.6 | 88.2 |
| MinimatD/150-675-4.5 | 4.5 | 48.4 | 0.5*9 | 20*29.1 | 675 | 2.9 | 78.4 |
| MinimatD/150-750-5.0 | 5.0 | 53.8 | 0.5*10 | 20*32.3 | 750 | 3.3 | 70.5 |
| MinimatD/150-900-6.0 | 6.0 | 64.6 | 0.5*12 | 20*38.8 | 900 | 3.9 | 58.8 |
| MinimatD/150-1050-7.0 | 7.0 | 75.3 | 0.5*14 | 20*45.2 | 1050 | 4.6 | 50.4 |
| MinimatD/150-1200-8.0 | 8.0 | 86.1 | 0.5*16 | 20*51.7 | 1200 | 5.2 | 44.1 |
| MinimatD/150-1350-9.0 | 9.0 | 96.9 | 0.5*18 | 20*58.1 | 1350 | 5.9 | 39.2 |
| MinimatD/150-1500-10 | 10 | 107.6 | 0.5*20 | 20*64.6 | 1500 | 6.5 | 35.3 |
| MinimatD/150-1800-12 | 12 | 129.2 | 0.5*24 | 20*77.5 | 1800 | 7.8 | 29.4 |
Why Choose Jiahong :
22 years experience made us to be the biggest manufacturer of heating cable in Asia. The only one have CE UL ETL TUV CSA certificate in Aisa. And 6-year's supplier of homedepot ,GE ,Grainger.
Products include heating mat ,heating cable ,thermostat and self regulating heating cable , All products approved and 100% inspected.Only adopts high-quality raw materials, key materials imported from American, Japan and Germany . It made our products with excellent quality .Better than any other competitors in China .
25-year warranty for underfloor heating system, 10-year warranty for self-regulating heating system; Deal and solve any of your concerns at the earliest time
Besides, we have a new cable only 2mm thickness.
