• Model NO.：Alarm cable
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, RoHS, SGS,ETL,CPR
• Brand：Risun or OEM
• Color：as Request
• Transport Package：100m,Coil, 4coils,Carton
• Specification：ETL, CE, RoHS, SG, ISO9001
• Trademark：Risun or OEM
• Origin：Hangzhou, China(Mainland)
• Production Capacity：20000 Boxes , Mont

Basic Info.

Model NO. Alarm cable Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CE, RoHS, SGS/ETL/CPR Brand Risun or OEM Color as Request Transport Package 100m/Coil, 4coils/Carton Specification ETL, CE, RoHS, SG, ISO9001 Trademark Risun or OEM Origin Hangzhou, China(Mainland) Production Capacity 20000 Boxes / Mont

Product Description

High quality Selling 4 cores Unshield Security Cable

Unshielded alarm cable:

A general purpose of signal and alarm cable manufactured in 4, 6, 8, 10and 12 cores configurations. Each core consists of 4/0.22mm2 tinned copper wire that is insolated and oversheathed in FRPVC. This kind of cable is ideal for using in alarm installation or where low voltage is used.

Features
1. Conductor: 4x0.22mm2 tinned copper or bare copper wire, can 2-40 cores.
2. Frame Retardant PVC insulation
3. Aluminum foil shielded
4. Ripcord
5. Frame Retardant PVC jacket

Shielded alarm cable:

Features
1. Conductor: 4x0.22mm2 tinned copper or bare copper wire, can 2-40 cores.
2. Frame Retardant PVC insulation
3. Aluminum foil shielded
4. Drain wire
5. Ripcord
6. Frame Retardant PVC jacket

Packing:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;

Usage: Security alarm
Certificate: CE, RoHS, ISO9001, ETL

SERIAL No.	SECTION	SPEICIFICATION	OVERALL DIAM. mm	WEIGHT (KG/KM)
RS-AL01	2*0.22mm2	2*7/0.20	3	11
RS-AL02	4*0.22mm2	4*7/0.20	3.5	18
RS-AL03	6*0.22mm2	6*7/0.20	4.1	25
RS-AL04	8*0.22mm2	8*7/0.20	4.5	32
RS-AL05	10*0.22mm2	10*7/0.20	5.2	39
RS-AL06	12*0.22mm2	12*7/0.20	5.4	46
RS-AL07	14*0.22mm2	14*7/0.20	5.8	54
RS-AL08	20*0.22mm2	20*7/0.20	6.8	76
RS-AL09	30*0.22mm2	30*7/0.20	8.4	114
RS-AL10	40*0.22mm2	40*7/0.20	10	148
