Nicr30/20 Alloy Wire High temperature alloy
Shanghai Tankii Alloy Material Co., Ltd.- Type：Bare
- Conductor Type：Solid
- Application：Heating
- Conductor Material：Nicrfe
- Insulation Material：Bare
- Melting Point：1390′c
Base Info
- Model NO.：NiCr30,20
- Transport Package：Spool, Coil, Wooden Case
- Specification：0.02~8mm
- Trademark：TANKII
- Origin：China
- HS Code：7223000000
- Production Capacity：5000tons,Year
Description
Max
0.08
0.02
0.015
1.0
1.0-3.0
18.0~21.0
30.0-34.0
Bal.
-
Mechanical Properties
Max Continuous Service Temperature:
Resisivity 20ºC:
Density:
Thermal Conductivity:
Coefficient of Thermal Expansion:
Melting Point:
Elongation:
Micrographic Structure:
Magnetic Property:
1100ºC
1.04+/-0.05 ohm mm2/m
7.9 g/cm3
43.8 KJ/m·h·ºC
19×10-6/ºC (20ºC~1000ºC)
1390ºC
Min 20%
Austenite
nonmagnetic
Material: NiCr30/20.
Resisivity: 1.04uΩ . M, 20'C.
Density: 7.9g/cm3.
Max Continuous Service Temperature: 1100'C
Melting point: 1390'C.
Application:
1. Used in the explosives and fireworks industry as a bridgewire in electric ignition systems.
2. Industrial and hobby hot wire foam cutters.
3. Testing the colour of the flame in the non-luminous part of fire of a cation.
4. Used in ceramics as an internal support structure.
Packaging: A full range of flexible packaging options are available to fit your individual requirements.
We professionally produce nickel-base alloy tape, include Ni80Cr20, Ni60Cr23, Ni60Cr16, Ni35Cr20, Ni20Cr25, NiMn, Ni200, Karma, Evanohm, NCHW, etc.
