GYTA Optical Fiber Cable/Computer Cable/ Data Cable/ Communication Cable/ Connector/Cable
Zhejiang Kuayue Cable Co., Ltd.- Application:Local Communication Cable, Fiber Optic Cable, Long Distance Symmetric Cable, Submarine Cable
- Conductor Material:Glasses
- Cover Material:PE
- Type:Single-Mode Fiber
- Material Shape:Round Wire
- Conductor Type:Single-Mode Fiber
Base Info
- Wire Core Material:Glasses
- Certification:CE, ISO, RoHS
- Model:GYTA Optical Cable
- Brand:Hanli
- Specification:4-72c
- Trademark:hanxin
- Origin:Zhejiang
- HS Code:8544700000
- Production Capacity:1000000m,Month
Description
Optical Cables--Stranded Loose Tube Non-armored Cable
GYTA Optical cable construction:
The coloring fiber are positioned in a central loose tube and Fillers are stranded around the metallic central strength member, it pass SZ into a compact, the APL is longitudinal covering, the cable is completed with PE sheath.In the loose tube, gap of the core is filled with the water-
Fiber CountNominal Weight(kg/km) Nominal Weight(lb/kft) Nominal Outer Diameter(mm) Nominal Outer Diameter(in) Maximum Pulling Load Installation(N/Ib) In Service(N/Ib) 2-36 110.0 73.83 120. 0.472 2670/600 800/180 38-72 120.0 80.54 12.6 0.496 2670/600 800/180 74-84 135.0 90.60 13.5 0.531 2670/600 800/180 76-96 150.0 100.67 14.0 0.551 2670/600 800/180 98-108 170.0 114.09 15.0 0.590 2670/600 800/180 110-120 190.0 127.52 15.5 0.610 2670/600 800/180 122-132 210.0 140.94 16.5 0.649 2670/600 800/180 134-144 230.0 154.36 17.5 0.688 2670/600 800/180 146-216 250.0 167.79 18.0 0.708 2670/600 800/180 218-264 300.0 201.34 19.5 0.767 2670/600 800/180 266-312 350.0 234.90 21.0 0.826 2670/600 800/180 314-360 400.0 268.46 22.5 0.885 2670/600 800/180 Fiber CountNominal Weight(kg/km) Nominal Weight(lb/kft) Nominal Outer Diameter(mm) Nominal Outer Diameter(in) Maximum Pulling Load Installation(N/Ib) In Service(N/Ib) 2-36 210.0 140.94 15.0 0.590 2670/600 800/180 38-72 230.0 154.36 15.5 0.610 2670/600 800/180 74-84 250.0 167.79 16.5 0.649 2670/600 800/180 76-96 270.0 181.21 17.0 0.669 2670/600 800/180 98-108 295.0 197.98 17.5 0.688 2670/600 800/180 110-120 320.0 214.77 18.5 0.728 2670/600 800/180 122-132 355.0 238.26 19.0 0.748 2670/600 800/180 134-144 370.0 248.32 20.0 0.787 2670/600 800/180 146-216 390.0 261.74 21.0 0.826 2670/600 800/180 218-264 455.0 305.35 22.5 0.885 2670/600 800/180 266-312 515.0 345.64 24.0 0.944 2670/600 800/180 314-360 580.0 389.26 26.0 1.023 2670/600 800/180
Welcome to visit our factory and get our samples.
Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
Website: http://kuayuecable.en.made-in-china.com http://kuayuecable.en.made-in-china.com
The coloring fiber are positioned in a central loose tube and Fillers are stranded around the metallic central strength member, it pass SZ into a compact, the APL is longitudinal covering, the cable is completed with PE sheath.In the loose tube, gap of the core is filled with the water-
