• Model NO.：SFT3302F
• Wavelength (±20nm)：650nm
• Power：10MW,Classiii B
• Range：12km
• Connector：FC,Upc
• Proof：IP65 (IEC60529)
• Launching Mode：Cw,2Hz
• Power Supply：10V(DC), 100V(AC) to 240V(AC), 50~60Hz
• Data Storage：Internal Memory: 4GB (About 40,000 Groups of Curv
• Transport Package：Brown Box
• Trademark：Softel
• Origin：Hangzhou, Zhejiang, China
• HS Code：9031801000
• Production Capacity：1000PCS Per Month
• Package size per unit product：20.00cm * 15.00cm * 8.00cm
• Gross weight per unit product：2.000kg

Applicable fibers

SM MM DS NZDS

Fiber diameter

Cladding diameter:80-150μm;Coating diameter:100-1000μm

Fiber aligning method

Meticulous,Core,Clad,Manual

Actual average splice loss

0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)

Typical splicing time

Typical 9 sec (standard SM fiber)

Tube typical heating time

Typical 30 sec

Storage of splice

result

4000 results, 20 parameter per result

Fiber image magnification

200X (X or Y view),50X (X and Y view)

Battery capacity

Typical 300 cycles (splice/tube heat with inner Li-battery)

Monitor

3.5 inch TFT color LCD monitor

Power supply

AC 100-240V with AC adapter inner Li-battery (5200mAH)

Dimension

25mm(L)×105mm(W)×113mm(H)

Fiber cleaved length

8-16mm (Coating diameter:250μm)

Fiber count

Single

Return loss

>60dB

Splicing mode

Auto Calibrate Normal Special

Splicing program

53 (templet), 40(user)

Protection sleeve length

60mm, 40mm

Tube heating program

9 (templet),24(user)

Tension test

2N

Electrode life

2500

Terminal

USB

Operating condition

0-5000m above sea level, -10-50° Max wind velocity of 15m/s

Weight

1.55Kg including battery
