• Shield：Aluminum Shield
• Jacket：LSZH (B2ca S1d0)
• Conductor 1：0.56+,-0.01m
• Conductor 2：0.58+,-0.01mm
• Transport Package：305m,Wooden Drum
• Origin：Hangzhou, Zhejiang, China
• HS Code：8544491100
• Production Capacity：20000 Boxes , Month

Basic Info.

Shield Aluminum Shield Jacket LSZH (B2ca S1d0) Conductor 1 0.56+/-0.01m Conductor 2 0.58+/-0.01mm Transport Package 305m/Wooden Drum Origin Hangzhou, Zhejiang, China HS Code 8544491100 Production Capacity 20000 Boxes / Month

Product Description

Description

Cable consisting of insulated conductors copper foamed polyethylene and LSOH outer sheath.

Manufactured according to ISO/IEC 11801 & ANSI/TIA-568-C.2, IEC 60332-1.

Strong points:
High-speed transmission up to 1 Gbit/s.
Optimized performance for passing satellite signals (2150 MHz).
Grade 3 Satellite.

Specificities
This network cable, with 4 twisted pairs, can be installed inside a skirting board, or inside a technical housing duct.
It can also be installed inside a TPC sheath (Cable Protection Tubes).

Configuration

1. Conductor1: 0.56±0.01mm Bare copper
    Conductor2: 0.58±0.01mm Bare copper
2. Insulation: 1.30±0.05mm FPE
3. Shield: Al-laminated plastic foil overall
4. Sheath: LSZH
5.Fire Rating: B2ca s1d0

Application

Digital TV distribution (CATV, TNT), Satellite 2200 MHz, Ethernet 100 Mbps, telephony + ADSL on RJ-45 socket (UTE C 90483 compliant)

Packing
1) packing lengths: 305m/wooden drum,500m/wooden drum or other lengths available according to client's request.
2) inner packing: wooden reel, plastic reel, and paper reel available.
3) outer packing: carton box, pull box
4) other packing available according to client's request.
