H07rn-F/A07rn-F 450/750V VDE Certificated Rubber Insulated Flexible Harmonized Rubber Cables
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Overhead, Underground
- Conductor Material:Copper
- Sheath Material:Pcp
- Insulation Material:Epr
Base Info
- Model NO.:H07rn-F,A07rn-F
- Material Shape:Round Wire
- Range of Application:Heating Units,Industrial Tools, Mobile Equipmentan
- Certification:ISO9001, CE, CCC, RoHS, VDE
- Brand:Fengda
- Color:Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly:Yes
- Whether Quality Inspection:Provide Inspection Certificate
- Standard:Customized According to Specified National Standar
- OEM/ODM:Accepted
- Core:Single Core and Multicore
- Transport Package:Standard Export Packaging
- Specification:International General Specifications
- Trademark:Fengda
- Origin:Tianjin, China(Mainland)
- HS Code:8544492100
- Production Capacity:100000,Day
Description
H07RN-F
Applications
These cables are designed for the connection of heating units,industrial tools, mobile equipmentand machines, e.g. vulcanisation plates,hand-operated equipment,transportable motors etc., undernormal mechanical loads in dry and damp areas, outdoors and in explosionhazard areas, as well as in industrialand agricultural applications and onbuilding sites.
Standards
DIN VDE 0282 Part1 and Part 4
HD 22.1
HD 22.4
Construction
Conductors: Strandedcopper conductor, class 5 according to DIN VDE 0295/HD 383 S2.
Insulation: Rubbertype EI4 according to DIN VDE 0282 Part 1/HD 22.1.
Inner Sheath(for ≥ 10 mm² ormore than 5 cores): EPR (Ethylene Propylene Rubber)
Outer Sheath: CR/PCP rubber type EM2.
Dimensions and Weight:
Number of Cores×Nominal Cross Section | Insulation Thickness | Thickness of Inner Sheath | Thickness of Outer Sheath | Minimum Overall Diameter | Maximum Overall Diameter | Nominal Weight |
No.×mm² | mm | mm | mm | mm | mm | kg/km |
1×1.5 | 0.8 | - | 1.4 | 5.7 | 6.7 | 60 |
2×1.5 | 0.8 | - | 1.5 | 8.5 | 10.5 | 120 |
3G1.5 | 0.8 | - | 1.6 | 9.2 | 11.2 | 170 |
4G1.5 | 0.8 | - | 1.7 | 10.2 | 12.5 | 210 |
5G1.5 | 0.8 | - | 1.8 | 11.2 | 13.5 | 260 |
7G1.5 | 0.8 | 1.0 | 1.6 | 14.0 | 17.0 | 360 |
12G1.5 | 0.8 | 1.2 | 1.7 | 17.6 | 20.5 | 515 |
19G1.5 | 0.8 | 1.4 | 2.1 | 20.7 | 26.3 | 795 |
24G1.5 | 0.8 | 1.4 | 2.1 | 24.3 | 28.5 | 920 |
1×2.5 | 0.9 | - | 1.4 | 6.3 | 7.5 | 75 |
2×2.5 | 0.9 | - | 1.7 | 10.2 | 12.5 | 170 |
3G2.5 | 0.9 | - | 1.8 | 10.9 | 13.0 | 230 |
4G2.5 | 0.9 | - | 1.9 | 12.1 | 14.5 | 290 |
5G2.5 | 0.9 | - | 2.0 | 13.3 | 16.0 | 360 |
7G2.5 | 0.9 | 1.1 | 1.7 | 17.0 | 20.0 | 510 |
12G2.5 | 0.9 | 1.2 | 1.9 | 20.6 | 23.5 | 740 |
19G2.5 | 0.9 | 1.5 | 2.2 | 24.4 | 30.9 | 1190 |
24G2.5 | 0.9 | 1.6 | 2.3 | 28.8 | 33.0 | 1525 |
1×4 | 1.0 | - | 1.5 | 7.2 | 8.5 | 100 |
2×4 | 1.0 | - | 1.8 | 11.8 | 14.5 | 195 |
3G4 | 1.0 | - | 1.9 | 12.7 | 15.0 | 305 |
4G4 | 1.0 | - | 2.0 | 14.0 | 17.0 | 400 |
5G4 | 1.0 | - | 2.2 | 15.6 | 19.0 | 505 |
1×6 | 1.0 | - | 1.6 | 7.9 | 9.5 | 130 |
2×6 | 1.0 | - | 2.0 | 13.1 | 16.0 | 285 |
3G6 | 1.0 | - | 2.1 | 14.1 | 17.0 | 380 |
4G6 | 1.0 | - | 2.3 | 15.7 | 19.0 | 550 |
5G6 | 1.0 | - | 2.5 | 17.5 | 21.0 | 660 |
1×10 | 1.2 | - | 1.8 | 9.5 | 11.5 | 195 |
2×10 | 1.2 | 1.2 | 1.9 | 17.7 | 21.5 | 565 |
3G10 | 1.2 | 1.3 | 2.0 | 19.1 | 22.5 | 715 |
4G10 | 1.2 | 1.4 | 2.0 | 20.9 | 24.5 | 875 |
5G10 | 1.2 | 1.4 | 2.2 | 22.9 | 27.0 | 1095 |
1×16 | 1.2 | - | 1.9 | 10.8 | 13.0 | 280 |
2×16 | 1.2 | 1.3 | 2.0 | 20.2 | 23.5 | 795 |
3G16 | 1.2 | 1.4 | 2.1 | 21.8 | 25.5 | 1040 |
4G16 | 1.2 | 1.4 | 2.2 | 23.8 | 28.0 | 1280 |
5G16 | 1.2 | 1.5 | 2.4 | 26.4 | 31.0 | 1610 |
1×25 | 1.4 | - | 2.0 | 12.7 | 15.0 | 405 |
4G25 | 1.4 | 1.6 | 2.2 | 28.9 | 33.0 | 1890 |
5G25 | 1.4 | 1.7 | 2.7 | 32.0 | 36.0 | 2335 |
1×35 | 1.4 | - | 2.2 | 14.3 | 17.0 | 545 |
4G35 | 1.4 | 1.7 | 2.7 | 32.5 | 36.5 | 2505 |
5G35 | 1.4 | 1.8 | 2.8 | 35.0 | 39.5 | 2718 |
1×50 | 1.6 | - | 2.4 | 16.5 | 19.5 | 730 |
4G50 | 1.6 | 1.9 | 2.9 | 37.7 | 42.0 | 3350 |
5G50 | 1.6 | 2.1 | 3.1 | 41.0 | 46.0 | 3804 |
1×70 | 1.6 | - | 2.6 | 18.6 | 22.0 | 955 |
4G70 | 1.6 | 2.0 | 3.2 | 42.7 | 47.0 | 4785 |
1×95 | 1.8 | - | 2.8 | 20.8 | 24.0 | 1135 |
4G95 | 1.8 | 2.3 | 3.6 | 48.4 | 54.0 | 6090 |
1×120 | 1.8 | - | 3.0 | 22.8 | 26.5 | 1560 |
4G120 | 1.8 | 2.4 | 3.6 | 53.0 | 59.0 | 7550 |
5G120 | 1.8 | 2.8 | 4.0 | 59.0 | 65.0 | 8290 |
1×150 | 2.0 | - | 3.2 | 25.2 | 29.0 | 1925 |
4G150 | 2.0 | 2.6 | 3.9 | 58.0 | 64.0 | 8495 |
1×185 | 2.2 | - | 3.4 | 27.6 | 31.5 | 2230 |
4G185 | 2.2 | 2.8 | 4.2 | 64.0 | 71.0 | 9850 |
1×240 | 2.4 | - | 3.5 | 30.6 | 35.0 | 2945 |
1×300 | 2.6 | - | 3.6 | 33.5 | 38.0 | 3495 |
1×630 | 3.0 | - | 4.1 | 45.5 | 51.0 | 7020 |
