• Model NO.：RG 11
• Brand：General Clad
• Center Conductor Material：Copper-clad steel wire
• Dielectric Material：Foam PE
• Jacket Material：PVC
• Inner Shield (Braid) Coverage：60 %
• Shield (Braid) Material：Aluminum
• Shield (Tape) Material：Aluminum,Poly
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Trademark：General Clad
• Origin：China
• Production Capacity：200km,Month

Cable TypeSeries 6Center Conductor TypeSolidConstruction TypeNon-armoredJacket ColorWhiteSupported ApplicationSatellite
DimensionsCable Length304.8 m | 1000 ftDiameter Over Center Conductor, specific0.0403 in per 1 strandDiameter Over Dielectric4.572 mm | 0.18 inDiameter Over Jacket Tolerance±0.008 inDiameter Over Jacket, nominal6.909 mm | 0.272 inDiameter Over Shield (Braid)5.385 mm | 0.212 inDiameter Over Shield (Tape)4.75 mm | 0.187 inJacket Thickness0.762 mm | 0.03 inJacket Thickness, minimum spot0.61 mm | 0.024 inCenter Conductor Gauge18 AWGShield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance28.6 ohms/kft | 93.832 ohms/kmDielectric Strength, conductor to shield3000 VdcJacket Spark Test Voltage2500 VacNominal Velocity of Propagation (NVP)82 %Shield dc Resistance9.7 ohms/kft | 31.824 ohms/kmStructural Return Loss15 dB @ 1000-3000 MHz | 20 dB @ 5-1000 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialCopper-clad steel wireDielectric MaterialFoam PEJacket MaterialPVCShield (Braid) Coverage60 %Shield (Braid) MaterialAluminumShield (Tape) MaterialAluminum/Poly
Package
